Baumer Photoelectric Sensors
type background: suppression
light source pulsed: red LED
operating temperature: -25 ... +60 °C
voltage supply: +Vs 10 ... 30 VDC
protection class: IP 67
| type | tolerance analysis |
| sensing distance Tw | 16 ... 120 mm |
| Teach-in range min. | > 0,4 mm |
| operating temperature | 0 ... +50 °C |
| type | window analysis |
| sensing distance Tw | 16 ... 120 mm |
| Teach-in range min. | > 0,4 mm |
| operating temperature | 0 ... +50 °C |
| type | measuring mode: edges, center, width, gap |
| version | PosCon 3D |
| measuring range (width) | 75 ... 125 mm |
| output circuit | analog and RS 485 |
art. 10159116
| type | measuring mode: edges, width |
| measuring field size | 24 mm |
| measuring distance (to object) | 0 ... 40 mm |
| operating temperature | 0 ... +55 °C |
art. 10224638
- art.: 10224638
- through beam sensor
- object size: > 0,8 mm
art. 10149511
| type | background suppression |
| light source | pulsed red LED |
| sensing distance Tw | 10 ... 60 mm |
| operating temperature | -20 ... +50 °C |
art. 10149512
| type | background suppression |
| light source | pulsed red LED |
| sensing distance Tw | 10 ... 60 mm |
| operating temperature | -20 ... +50 °C |
art. 10146074
- through beam sensor
- art.10146074
- nominal range: 6 m
art. 11001167
Diffuse sensors with background suppression
- art. 11001167
- 20 … 350 mm
- pulsed red LED
- PNP
art. 11001165
| type | background suppression |
| light source | pulsed red LED |
| sensing distance Tw | 20 ... 350 mm |
| operating temperature | -25 ... +65 °C |
Baumer FHDM 12P5001/S35A Diffuse sensor, background suppression withsensing distance 15 ... 300 mm.
art. 10146052
- art.: 10146052
- range: 20-450 mm,
- 10-30 VDC,
- PNP
- IP67
art. 10234192
| type | retro-reflective sensor |
| light source | pulsed red LED |
| actual range Sb | 5 m |
| operating temperature | -25 ... +65 °C |
art. 10127710
| type | intensity difference |
| light source | pulsed infrared diode |
| sensing distance Tw | 60 ... 430 mm |
| operating temperature | -25 ... +55 °C |
art. 11136921
| type | light barrier |
| version | transparency object detection |
| light source | pulsed PinPoint LED |
| operating temperature | -25 ... +60 °C |
art. 11136924
| type | light barrier |
| special type | Washdown design |
| version | transparency object detection |
| operating temperature | -25 ... +60 °C |
| type | through beam sensor |
| object size | > 0,05 mm |
| repeat accuracy | < 0,01 mm |
| operating temperature | 5 ... +45 °C |
art. 11001254
| type | background suppression |
| light source | pulsed red laser diode |
| sensing distance Tw | 20 ... 350 mm |
| operating temperature | -10 ... +50 °C |
| type | background suppression |
| light source | pulsed red laser diode |
| sensing distance Tw | 50 ... 550 mm |
| operating temperature | 0 ... +50 °C |
| type | through beam sensor |
| emitter / receiver | receiver |
| actual range Sb | 16 m |
| operating temperature | -25 ... +55 °C |
| type | through beam sensor |
| emitter / receiver | receiver |
| actual range Sb | 16 m |
| operating temperature | -25 ... +55 °C |
art. 10152097
| type | through beam sensor |
| emitter / receiver | receiver |
| actual range Sb | 2 m |
| operating temperature | -20 ... +50 °C |
art. 10151070
| type | through beam sensor |
| emitter / receiver | receiver |
| actual range Sb | 2 m |
| operating temperature | -20 ... +50 °C |
art. 10151071
| type | through beam sensor |
| emitter / receiver | receiver |
| actual range Sb | 2 m |
| operating temperature | -20 ... +50 °C |
art. 10146078
| type | through beam sensor |
| emitter / receiver | receiver |
| actual range Sb | 5 m |
| operating temperature | -25 ... +65 °C |
art. 10146079
| type | through beam sensor |
| emitter / receiver | receiver |
| actual range Sb | 5 m |
| operating temperature | -25 ... +65 °C |
art. 10139963
| type | through beam sensor |
| emitter / receiver | receiver |
| actual range Sb | 5 m |
| operating temperature | -25 ... +65 °C |
art. 10131284
| type | through beam sensor |
| emitter / receiver | receiver |
| actual range Sb | 5 m |
| operating temperature | -25 ... +65 °C |
art. 11001030
| type | through beam sensor |
| emitter / receiver | receiver |
| actual range Sb | 12 m |
| operating temperature | -25 ... +65 °C |
