Siemens Flow meters SITRANS F

Choose a subcategory:

Show all categories

f mag

Measuring range:

  • Flow velocity: 0.01 to 10 m/s (0.03 to 33 ft/s)
  • Volumetric flow rate: 0.005 to 10000 m³/h (0.17 to 353170 ft³/h)
  • Mass flow rate: 0.01 to 1000000 kg/h (0.022 to 2204622 lb/h)

Accuracy:

  • ±0.5% of the measured value
  • ±0.2% of the measured value (optional)

E FLASSY 300MM PN6,10

MAG 3100 AISI 316 GROUNDING RING TYP E FOR PTFE LINER, 18 INCH, CLASS 300

MAG 3100 E FLANGE 2 1/2 INCH, CL150, CL300 HAST C

MAG 3100 E FLANGE 4 INCH, CL150 HAST C

MAG8000 ACCESSORIES INTERNAL BATTERY P1039

MAG8000 ACCESSORIES, EXTERNAL BATTERY PACK IP68/NEMA 6P WITH CONNECTOR, 4 D-CELL (3.6 V 66 AH) WITHOUT POWER CABLE.

MAG8000 ACCESSORIES FLOW TOOL CONFIGURATION SOFTWARE CD

mag 5000 d

Power Supply:

  • Supply voltage: 24 V AC/DC
  • Power consumption: 10 VA

Output signals:

  • Analog: 4-20 mA
  • Digital: pulse, HART

mag3100p

  • Measuring range: 0.01 m/s to 10 m/s (0.033 ft/s to 32.8 ft/s)
  • Repeatability: ±0.2% of the measured value
  • Response time: < 1 second

siemens 2100

Communication protocols:

  • Modbus RTU
  • Modbus TCP
  • HART

siemens mass flow 6000

  • Degree of protection: IP67
  • Mounting: Flanged, threaded
  • Power supply range: 24 V DC, 110 ... 230 V AC

siemens 7me

  • Power supply voltage: 24 V AC/DC, 110-230 V AC
  • Degree of protection: IP65, IP67
  • Ambient temperature: -40°C ... +80°C
  • Relative humidity: Up to 95%.

siemens 7me3220

  • Voltage: 24 V AC/DC
  • Power consumption: ≤ 10 VA
  • Calibration certificate: optional
  • Certificates: ATEX, CSA, FM

siemens fs230

  • Sensor: PVC, PFA, stainless steel
  • Voltage: 20-27 V DC, 100-240 V AC, 47-63 Hz
  • Power consumption: < 25 watts per unit.

siemens fc300

Materials:

  • Body: stainless steel 1.4404 (316L)
  • Internal parts: stainless steel 1.4435 (316L)
  • Seals: EPDM

sitrans fc410

  • Compact design
  • Reliability
  • Ease of use
  • Versatility

siemens sitrans fc430

  • Power supply voltage: 100-240 VAC, 50/60 Hz
  • Power consumption: 25 VA

sitrans fcs400

  • Mounting: flanged
  • Protection class: IP67
  • Certificates: ATEX, IECEx, CSA, FM

siemens fs220

  • Built-in data logger
  • Output signal 0-10 V
  • HART 7
  • Profibus PA
  • Modbus TCP/IP

sitrans fst020

Operating temperature range:

  • -20 ... +80 °C (standard)
  • -40 ... +120 °C (optional)

Maximum pressure:

  • PN16 (standard)
  • PN40 (optional)

sitrans fst030

Operating temperature range:

  • Liquids: -20 ... +150 °C
  • Gases: -20 ... +60 °C

Maximum pressure:

  • PN16 (up to 16 bar)
  • PN40 (up to 40 bar)

sitrans fug1010

Temperature range:

  • -40°C ... +150°C (standard)
  • -200°C ... +200°C (optional)

Maximum pressure:

  • PN40 (standard)
  • PN160 (optional)

sitrans fuh1010

Pipe diameter: DN15 ... DN250
Measurement type: ultrasonic
Number of channels: 1
Power supply: 24 V DC
Degree of protection: IP67
Explosion protection: ATEX

siemens sitrans fus060

Interfaces:

  • RS-232
  • HART
  • PROFIBUS PA (optional)

sitrans fus1010

  • Voltage: 24 V DC
  • Power consumption: ≤ 3.5 W

Outputs:

  • Analog output: 4...20 mA
  • Digital output: pulse, RS-485

fus380

  • Operating temperature range: -25°C ... +150°C (-13°F ... +302°F)
  • Operating pressure range: PN10 ... PN40 (145 psi ... 580 psi)
  • Power supply: 110-230 VAC, 24 VAC/VDC

sono 3300

  • Explosion-proof enclosure
  • ATEX certificate
  • Temperature sensor
  • Software for configuration and monitoring

siemens sono

  • Pipe diameter: DN15 to DN600
  • Maximum pressure: PN16 to PN400
  • Output signal: pulse (4-20 mA), analog (0-10 V), digital (RS485)
  • Degree of protection: IP67
  • Certificates: ATEX, IECEx, CSA

siemens sonokit

  • Pressure range: PN10 to PN40
  • Degree of protection: IP68
  • Explosion protection: ATEX, IECEx
  • Certificates: MID, CE
  • Electrode materials: PEEK, Hastelloy C, titanium
