Baumer TDP 0,2 + FSL

Tachogenerators and Resolvers
Baumer TDP 0,2 + FSL
Price on Request
One click request
Weight approx. 3.1 kg
Range of switching speed (ns) 850...4500 rpm
(Δn = 2 rpm/s)
Isolation class B
Minimum switching current 50 mA
Performance 12 W (speed ≥3000 rpm)
Climatic test Humid heat, constant
(IEC 60068-2-3, Ca)
Flange EURO flange B10
Interference immunity EN 61000-6-2
Emitted interference EN 61000-6-3
Temperature coefficient ±0.05 %/K (open-circuit)
Approval CE
Torque 1.5 Ncm
Switching outputs 1 output, speed control
Output switching capacity ≤6 A / 230 VAC
≤1 A / 125 VDC
Speed (n) ≤1.25 · ns
Operating temperature -30...+130 °C
Linearity tolerance ≤0.15 %
Switching deviation cw-ccw rotation ≤3 %
Resistance IEC 60068-2-6
Vibration 5 g, 10-2000 Hz
IEC 60068-2-27
Shock 150 g, 1 ms
Shaft type ø11 mm solid shaft
Materials Housing: aluminium die-cast
Shaft: stainless steel
Rotor moment of inertia 1.4 kgcm²
Switching accuracy ±4 % (Δn = 2 rpm/s);
= +20 % (Δn = 1500 rpm/s)
Reversal tolerance ≤0.1 %
Protection DIN EN 60529 IP 55
Admitted shaft load ≤60 N axial
≤80 N radial
Open-circuit voltage 10...150 mV per rpm
Switching hysteresis ~40 % of switching speed
Connection 2x terminal box
manufacter SKUTDP 0,2 + FSL
Armature-circuit time-constant
Calibration tolerance ±1 %
Size (flange) ø115 mm
