Baumer Miniature Photoelectric Sensors
art. 11230138
- Most secure object detection due to the barrier principle
- Manipulation-proof, simple teach-in via qTeach or line teach
- IO-Link for extended parameterization options and additional diagnostic data
- Quick mounting by means of M3 threaded bushes made of stainless steel
art. 11229194
- Most secure object detection due to the barrier principle
- IO-Link interface independent of the switching output (Dual Channel)
- Extended parameterization options and additional diagnostic data
- Robust housing with stainless steel spacer sleeves
art. 11210570
- Most secure object detection due to the barrier principle
- Easy to adjust via line teach
- Intiutive Xpress Teach / 1-Step Teach method
- Quick mounting by means of M3 threaded bushes made of stainless steel
art. 11230775
- Outstanding reliability and unrivalled immunity against ambient light
- Line beam for complete detection of irregular, perforated objects
- Precise detection thanks to laser light source
- Manipulation-proof, simple teach-in via qTeach or line teach
- IO-Link for extended parameterization options and additional diagnostic data
- Quick mounting by means of M3 threaded bushes made of stainless steel
art. 11212696
- Outstanding reliability and unrivalled immunity against ambient light
- Baumer PinPoint LED: Small, homogeneous light spot with sharp edges
- Manipulation-proof, simple teach-in via qTeach or line teach
- IO-Link for extended parameterization options and additional diagnostic data
- Quick mounting by means of M3 threaded bushes made of stainless steel
art. 11212612
- Outstanding reliability and unrivalled immunity against ambient light
- Baumer PinPoint LED: Small, homogeneous light spot with sharp edges
- qTeach - tamper-proof, simple teach-in with ferromagnetic tool
- Robust housing with stainless steel spacer sleeves
art. 11210549
- Outstanding reliability and unrivalled immunity against ambient light
- Baumer PinPoint LED: Small, homogeneous light spot with sharp edges
- qTeach - tamper-proof, simple teach-in with ferromagnetic tool
- Robust housing with stainless steel spacer sleeves
art. 11211249
- Outstanding reliability and unrivalled immunity against ambient light
- Easy to adjust via line teach
- Intiutive Xpress Teach / 1-Step Teach method
- Quick mounting by means of M3 threaded bushes made of stainless steel
art. 11210939
- Outstanding reliability and unrivalled immunity against ambient light
- Easy to adjust via line teach
- Intiutive Xpress Teach / 1-Step Teach method
- Robust housing with stainless steel spacer sleeves
art. 11210542
- Outstanding reliability and unrivalled immunity against ambient light
- Reproducible and color-independent switching distances
- Fixed preset for the simplest commissioning
- Robust housing with stainless steel spacer sleeves
art. 11210540
- Outstanding reliability and unrivalled immunity against ambient light
- Reproducible and color-independent switching distances
- Fixed preset for the simplest commissioning
- Robust housing with stainless steel spacer sleeves
art. 11210541
- Outstanding reliability and unrivalled immunity against ambient light
- Reproducible and color-independent switching distances
- Fixed preset for the simplest commissioning
- Robust housing with stainless steel spacer sleeves
art. 11210565
- Outstanding reliability and unrivalled immunity against ambient light
- Reproducible and color-independent switching distances
- Fixed preset for the simplest commissioning
- Quick mounting by means of M3 threaded bushes made of stainless steel
art. 11212631
- Outstanding reliability and unrivalled immunity against ambient light
- Reproducible and color-independent switching distances
- Fixed preset for the simplest commissioning
- Quick mounting by means of M3 threaded bushes made of stainless steel
art. 11210545
- Outstanding reliability and unrivalled immunity against ambient light
- V-optics for detection of shiny or transparent objects
- Manipulation-proof, simple teach-in via qTeach or line teach
- IO-Link for extended parameterization options and additional diagnostic data
- Robust housing with stainless steel spacer sleeves
art. 11212636
- Outstanding reliability and unrivalled immunity against ambient light
- V-optics for detection of shiny or transparent objects
- Manipulation-proof, simple teach-in via qTeach or line teach
- IO-Link for extended parameterization options and additional diagnostic data
- Quick mounting by means of M3 threaded bushes made of stainless steel
art. 11231164
- SmartReflect - Safe barrier principle without reflector
- qTeach - tamper-proof, simple teach-in with ferromagnetic tool
- Robust housing with stainless steel spacer sleeves
art. 11231167
- SmartReflect - Safe barrier principle without reflector
- Long-term stable detection of transparent objects thanks to compensation of environmental influences
- Manipulation-proof, simple teach-in via qTeach or line teach
- IO-Link for extended parameterization options and additional diagnostic data
- Robust housing with stainless steel spacer sleeves
art. 11210276
- SmartReflect - Safe barrier principle without reflector
- Baumer PinPoint LED: Small, homogeneous light spot with sharp edges
- Manipulation-proof, simple teach-in via qTeach or line teach
- IO-Link for extended parameterization options and additional diagnostic data
- Robust housing with stainless steel spacer sleeves
art. 11212658
- SmartReflect - Safe barrier principle without reflector
- Baumer PinPoint LED: Small, homogeneous light spot with sharp edges
- Manipulation-proof, simple teach-in via qTeach or line teach
- IO-Link for extended parameterization options and additional diagnostic data
- Quick mounting by means of M3 threaded bushes made of stainless steel
art. 11210555
- SmartReflect - Safe barrier principle without reflector
- Baumer PinPoint LED: Small, homogeneous light spot with sharp edges
- qTeach - tamper-proof, simple teach-in with ferromagnetic tool
- Robust housing with stainless steel spacer sleeves
art. 11167265
- receiver
- through beam sensor
- 10 m
- push-pull
- qTeach / remote
- cable 4 pin, 2 m
- -25 ... 60 °C
- IP 67
art. 11128044
- receiver
- through beam sensor
- 10 m
- push-pull
- qTeach / remote
- connector M8 4 pin
- -25 ... 60 °C
- IP 67
art. 11171741
- background suppression
- 30 ... 250 mm
- pulsed red laser diode
- push-pull
- Teach-in and IO-Link
- connector M8 4 pin
- -10 ... 60 °C
- IP 67
art. 11171745
- background suppression
- 30 ... 250 mm
- pulsed red laser diode
- NPN complementary
- qTeach
- cable 4 pin, 2 m
- -10 ... 60 °C
- IP 67
art. 11171748
- background suppression
- 30 ... 250 mm
- pulsed red laser diode
- PNP complementary
- qTeach
- connector M8 4 pin
- -10 ... 60 °C
- IP 67
art. 11172767
- retro-reflective sensor
- 5 m
- pulsed red laser diode
- push-pull
- Teach-in and IO-Link
- cable 4 pin, 2 m
- -10 ... 60 °C
- IP 67
art. 11172803
- retro-reflective sensor
- 5 m
- pulsed red laser diode
- PNP complementary
- qTeach
- connector M8 4 pin
- -10 ... 60 °C
- IP 67
art. 11181088
- intensity difference
- 10 ... 250 mm
- pulsed red laser diode
- PNP complementary
- qTeach
- cable 4 pin, 2 m
- -10 ... 60 °C
- IP 67
art. 11171769
- background suppression
- 30 ... 250 mm
- pulsed red laser diode
- push-pull
- Teach-in and IO-Link
- flylead connector M8, L=200 mm
- -10 ... 60 °C
- IP 68/69K & proTect+
Photoelectric sensors are non-contact sensors that use visible or infrared light to detect objects. They emit light beams and watch the beam for any interruptions or changes to detect the presence of any foreign object within the light path.
In this article, we'll take a look at the Baumer miniature photoelectric sensors.
What is a Baumer Miniature Photoelectric Sensor?
Photoelectric sensors detect objects, measure distances, recognize colors, count components, and monitor filling levels. The production of newspapers, chocolate, cars, computers, and cell phones would be unthinkable without sensors. Delivering letters and parcels would be very labor intensive and food handling would be cumbersome. Modern technologies allow the production of compact photoelectric sensors that are able to accurately detect objects with high repetition accuracy even in harsh industrial environments.
As for the advantages of this type of sensor, there are many of them. Among them you will find:
- Robust housing made of stainless steel, metal, and plastic for various applications.
- High resistance to scattered light.
- Vibration-resistant sensors and sensors in IP 69K version.
- Low-temperature drift in case of ambient temperature fluctuations.
- Reliable and efficient processes.
- The point, line, or multi-point beamform for reliable measurements in the submicrometer range on non-homogeneous surfaces.
- High precision down to the micrometer.
- Precise positioning of objects with non-linearity ± 0.06%.
- Intelligent signal processing inside the sensor.
- Fast measurements thanks to short measuring cycles.
- Fast and economical installation with Plug & Play.
- Easy and quick adjustment of the measuring range with the teach button.
- Innovative touch display with a simple operating concept.
- Factory-calibrated sensors with measured values in millimeters.
Here are some of Baumer's miniature photoelectric sensors applications.
- Measuring the thickness of metal, ceramics, wood panels, or rubber bands.
- High-precision distance measurements, e.g. in quality control.
- Position feedback in industrial automation.
- Level control, e.g. in the packaging industry.
Technical Data About Baumer Miniature Photoelectric Sensors
Versatile applications require laser distance sensors with versatile characteristics. In addition to the different sizes and ranges, the type of measuring beam plays a particularly important role. Through continuous development, Baumer is able to offer a new "multi-point" measurement principle with three different beam shapes:
- Laser point: measurement of small objects with a spot size <0.4 mm.
- Laser line: measurements on rough surfaces.
- Multipoint laser line: measurements on extremely rough and inhomogeneous shiny surfaces with very wide laser lines <62 mm.
Here is a list of more detailed specifications for sensors miniature from Baumer:
- Miniature Sensors O200
- Size from 8 mm
- Configurable via qTeach or IO-Link
- LED and laser with qTarget
- Extremely high resistance to ambient light
- Point and line beam shape
- Dispersive sensors up to 200 mm
- Cross-beam sensor up to 6 m
O300 High Power Series
- Size 12.9mm
- High-power sensors in plastic or stainless steel housing
- Laser, red light, and infrared LED with qTarget
- Point and line versions
- Reflective barriers up to 300 mm
- Cross-beam sensors up to 75 m
OT300 Series Miniature Sensors
- Miniature body measuring 12.9 x 32.3 x 23 mm
- Extended measurement range up to 1.8 m
- Distance measuring version 0-10 V DC AC, background suppressor or SmartReflect - light barrier without reflector
- IO-Link interface
