Baumer My-Com Sensors
art. 10118664
| repeat accuracy | < 0,001 mm |
| activating force | 100 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10251043
| repeat accuracy | < 0,001 mm |
| activating force | 30 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10238646
| repeat accuracy | < 0,001 mm |
| activating force | 250 cN |
| mech. pre-run / overrun | 1 mm / 1 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10222682
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 0,8 ... 1,5 mm approx. |
| output circuit | NPN make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10211843
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 0,8 ... 1,5 mm approx. |
| output circuit | PNP make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10240974
| repeat accuracy | < 0,001 mm |
| activating force | 30 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10239283
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | NPN make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10258550
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | NPN make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10221003
| voltage supply | 5 … 36 VDC |
| load current | 24 VDC 50 mA |
| operating temperature | -20 … +75 °C |
art. 10228788
Baumer my-com pecision switch
| Product type | Precision Mechanical Switches |
| Weight | 2 lbs |
art. 10238397
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | PNP make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10251037
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 0,6 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10238645
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 0,6 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10239878
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 0,6 mm approx. |
| output circuit | NPN make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10222699
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 0,6 mm approx. |
| output circuit | PNP make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10238477
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 0,6 mm approx. |
| output circuit | PNP make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10222703
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 0,6 mm approx. |
| output circuit | PNP make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10238800
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10242627
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | NPN make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10124556
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | PNP make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10229687
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | PNP make function (NO) |
| operating temperature | -20 ... +75 °C |
art. 10251036
| repeat accuracy | < 0,001 mm |
| activating force | 250 cN |
| mech. pre-run / overrun | 1 mm / 1 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10221367
- break function (NC) mechanical
- cable, 2 m
- -20 ... 75 °C
- IP 50
art. 10251051
| repeat accuracy | < 0,001 mm |
| activating force | 100 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10240394
| repeat accuracy | < 0,001 mm |
| activating force | 100 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10251048
| repeat accuracy | < 0,001 mm |
| activating force | 30 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10241610
| repeat accuracy | < 0,001 mm |
| activating force | 30 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10223784
- break function (NC) mechanical
- cable, 2 m
- -20 ... 75 °C
- IP 50
art. 10251049
| repeat accuracy | < 0,001 mm |
| activating force | 50 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
art. 10251050
| repeat accuracy | < 0,001 mm |
| activating force | 75 cN |
| mech. pre-run / overrun | - / 1,5 mm approx. |
| output circuit | break function (NC) mechanical |
| operating temperature | -20 ... +75 °C |
Baumer my-com sensors is one of the most accurate precision mechanical switch in the World. Its repeat accuracy is equal to 1 μm (0.001m) and this indicator is almost independent of the environment.
The German company produces several categories of sensors My-com:
- All mechanical
- With amplifier
- For lateral approach
- Rugged IP67
Devices are available with both mechanical (NC) and electrical (PNP / NPN) output circuit. Such equipment has a robust and at the same time compact design. This is achieved due to brass nickel-plated housing.
Devices have a protection level of IP50 or IP67. Activating pin is made of three types of material: zirconium oxide ZrO2, hardened steel and ruby. The equipment operates optimally at temperatures from -20 to + 75 °C (-4 to 167 °F).
Models with adjustable activation power from 30cN to 250cN are available. In addition, sensors were created with built-in amplifier and with LED for 50mA.
My com sensors are used in precision manufacturing, quality control, laboratory assemblies and other areas where high accuracy is demanded. The design consists of only three parts, which ens uses ease of operation and durability.
Baumer hubner precision switchers my com are great choices when you need very accurate results from small and durable sensors. They are the best worldwide in their class due to the technologies used.
