Eltra Encoder Absolute magnetostrictive transducer

Linear magnetostrictive transducer with analogue output.

Linear magnetostrictive transducer with analogue output.

Linear magnetostrictive transducer with analogue output.

Linear magnetostrictive rod transducer with analogue output.

Linear magnetostrictive transducer with analogue output.
Linear magnetostrictive transducer with analogue output.

Linear magnetostrictive transducer with SSI output.

Linear magnetostrictive rod transducer with analogue output.

ELTRA absolute magnetostrictive linear transducers are made of Improved magnetostrictive materials and don’t have electric contact on the enclosure.

So they have high reliability and simple installation. Also magnetostrictive technology guarantees great performances of speed and precision.
ELTRA magnetostrictive transducers can be used in environments with mechanical stresses, shocks or high contamination.

EMSPA

This series of linear absolute transducer has analog interface. There is no issue of wear and deterioration during working life due to their absence of electric contact on the enclosure.

Eltra EMSPA MAIN FEATURES:

  • Up to IP67 enclosure rating
  • Working temperature: -30° ... +100°C
  • Stroke length 50 - 1500 mm
  • Linearity 0,04%
  • Up to 10 m/s displacement speed
  • Sampling time  up to 1,5 ms

EMSPB

EMSPB series stands out for high precision and great performances of speed. Their  small size and rugged enclosure give easy installation and high reliability. They are perfect for using in application with shocks, mechanical stresses  and high contamination conditions.

ELTRA EMSPB MAIN FEATURES:

  • Up to IP65 enclosure rating
  • Working temperature: -20° ... +75°C
  • Stroke length  50 - 1500 mm
  • Up to 10 m/s displacement speed
  • Sampling time  up to 1,5 ms

EMSPS

This series of linear magnetostrictive transducer has digital RS422-SSI compliant output. There is no issue of wear and deterioration during working life due to their absence of electric contact on the enclosure.

ELTRA EMSPS MAIN FEATURES:

  • Up to IP67 enclosure rating
  • Working temperature: -30° ... +75°C
  • Stroke length 50 - 1500 mm
  • Linearity 0,04%
  • Up to 10 m/s displacement speed
  • Sampling time up to 1,5 ms
  • Up to 0,040 mm resolution

EMSSA

This series of linear transducer has analog interface. They can be mounted to high applications (350 bar, 700 bar peak). For example pneumatic cylinders or  hydraulic.

They are perfect for using in application with shocks, mechanical stresses and high contamination conditions due to rugged enclosure and compact size.

ELTRA EMSSA MAIN FEATURES:

  • Up to IP67 enclosure rating
  • Working temperature: -40° ... +70°C
  • Stroke length 50 - 1500 mm
  • Linearity 0,03%
  • Up to 10 m/s displacement speed
  • Sampling time up to 1,5 ms
  • Up to 0,040 mm resolution

EMSSS

linear transducer series with SSI output.

Due to their compactness and rugged housing, these encoders are ideal for applications where there are high mechanical loads, shocks and heavy pollution.

ELTRA EMSSS MAIN FEATURES:

  • Up to IP67 enclosure rating
  • Working temperature: -40° ... +70°C
  • Stroke length 50 - 1500 mm
  • Linearity 0,03%
  • Up to 10 m/s displacement speed
  • Sampling time up to 1,5 ms
  • Up to 0,040 mm resolution
