Lenze Frequency Inverters

Servo Drives 9400 HighLine, Single Drive, 59Aб, 30 kW

Safety module

Function modules

Modules for Servo Drives

A USB adapter can be used to diagnose the drive using a computer.

Frequency inverter

esv112n02yxc

Built-in functions:

• PID controller
• Flow regulator
• Torque regulator
• Automatic tuning function
• Motor protection function
• Energy saving function
• Ability to connect to PLC

esv152n02yxb

• Type of cooling: Convection
• Operating temperature range: -10°C ... +40°C
• Storage temperature range: -25°C ... +70°C
• Degree of protection: IP20
• EMC: EN 61800-3:2004
• Certificates: CE, UL, CSA

esv371n01sxb

Inputs/outputs:

• 1 analog input (0-10 V)
• 1 analog output (0-10 V)
• 4 digital inputs
• 2 digital outputs
• 1 RS-485 port

esv371n01sxc

• Control method: Sensorless Vector Control
• Rated torque: 1.8 Nm
• Overload capacity: 150% for 60 seconds
• Switching frequency: 2-16 kHz
• Energy efficiency: IE3
• Noise level: <50 dB
• Certificates: CE, UL, CSA

esv552n02txb

Digital inputs:

• 1 x Start/stop
• 3 x Programmable (4 x for models 15 hp (11 kW) and above)

Digital outputs:

• 1 x Form A relay
• 1 x Open collector

Analog inputs:

• 1 x Voltage (0-10 VDC)
• 1 x Current (4-20 mA)

esv752n02txb

• Analog inputs: 2 pcs, 0-10 V, 4-20 mA
• Digital inputs: 4 pcs.
• Relay outputs: 2 pcs.
• Analog output: 1 pc, 0-10 V
• Communication ports: RS-485

The 9300 Vector series of VFDs

Cabinet Drive

Frequency Drive

i550 Frequency inverter

Control Unit Standard-I/O

Control Unit Standard I/O with PROFIBUS-DP

Inverter

i550 STO Optional Module

• SI E70ACMDE
• 2x 20A SOA Enc 1F 2.16
