i550 protec is a new series of Lenze frequency converters with a power range from 0.37 to 22 kW (expansion to 75 kW is planned).
Features: compact design, scalability and exceptional ease of use.
In cases where your device needs a lot of free space or the device has a modular design, the i550 protec universal frequency converter provides you with the ideal solution - installation next to the motor. Converters in this series are ideal for many applications - conveyor systems, ventilation and pumping systems, packaging machines.
The i550 protec drives use technology that has already proven itself in i550 cabinet series devices; the only difference is the higher degree of protection of the case and the adapted design.
Benefits:
- The high protection degree IP 66 (NEMA 4X), which allows operation both indoors and outdoors, provides protection against water and dust and allows the use of i550 protec in harsh environments.
- The first decentralized drive on the market with an interface for connecting IO-Link devices.
- Vector control without feedback for synchronous motors.
- Intuitive interface provides quick setup and easy navigation when selecting options.
- Electronic software module (EPM) for easy commissioning and replacement of devices in this series.
- Built-in diagnostic interface USB Micro.
- Optionally equipped with a remote control or WiFi module.
That's how easy the i550 protec series inverters can be integrated
Three methods of adjustment
Thanks to a well-thought-out engineering approach, high functionality remains an indispensable attribute of all Lenze products. Adjusting the parameters and commissioning are impressive in their simplicity due to the clear structure and clear dialog boxes, which allows you to quickly and confidently achieve the desired result.
- Remote control. You only need to set a few key parameters, such as acceleration / deceleration time, that can be done fast with the remote control.
- SMART keypad application. The intuitive application, which is installed on a smartphone with Android or iOS, is easily adapted for easy use: for example, for conveyor systems.
- EASY Starter. If you need to specify functions such as motor potentiometer or sequence control for the positioning application, it is best to use the EASY Starter tool application.
Functions:
- Control on U / f characteristic of linear / quadratic dependence (VFC plus);
- Vector control without feedback (SLVC);
- Energy saving function (VFC eco);
- Servo control (SC-ASM) with feedback;
- Vector control without feedback for synchronous motors;
- Vector control with feedback, U / f – characteristic;
- Control using U / f feedback characteristics;
- DC braking;
- Brake performance control for low-wear brake control;
- Braking using a braking resistor;
- S-shaped curves for smooth acceleration and delay;
- Auto-pickup circuit, PID-regulator.
Safety technology: Safe torque shutdown (STO).
