Baumer O300.EL-NV1T.72CU
Through beam sensors - miniature
We ship to United States of America!
art. 11181069
- receiver
- through beam sensor
- 40 m
- NPN complementary
- qTeach
- cable 4 pin, 2 m
- -25 ... 60 °C
- IP 67
Item Number:
O300.EL-NV1T.72CU
The price is not final. Please check with the manager!
Contact our experts
- Overview
- Comments
| Baumer Article no | 11181069 |
| Type | Through beam sensor |
| Emitter / receiver | Receiver |
| Actual range Sb | 40 m |
| Nominal range Sn | 75 m |
| Alignment / soiled lens indicator | Flashing light indicator |
| Light indicator | LED yellow |
| Power on indication | LED green |
| Sensitivity adjustment | qTeach |
| Alignment optical axis | < 2В° |
| Response time / release time | < 0.49 ms |
| Voltage supply range +Vs | 10 ... 30 VDC |
| Current consumption max. (no load) | 40 mA |
| Current consumption typ. | 30 mA |
| Voltage drop Vd | < 3 VDC |
| Output function | Light / dark operate |
| Output circuit | NPN complementary |
| Output current | < 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 12.9 mm |
| Height / length | 32.3 mm |
| Depth | 23 mm |
| Type | Rectangular |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -25В ...В +60 В°C |
| Protection class | IP 67 |
