Baumer OG120U.L-GW1O.7WL
Fork sensors
art. 11229524
- through beam sensor
- 120 mm
- pulsed red laser diode
- Push-Pull
- potentiometer / IO-Link
- connector M8, 3 pin
- -25 ... 60 °C
- IP 67
Item Number:
OG120U.L-GW1O.7WL
The price is not final. Please check with the manager!
Contact our experts
- Overview
- Comments
| Baumer Article no | 11229524 |
| Type | Through beam sensor |
| Object size | > 0.2 mm |
| Repeat accuracy | 0.01 mm |
| Response time / release time | < 0.1 ms |
| Hysteresis | < 0.05 mm |
| Sensitivity adjustment | Potentiometer, 270В°IO-Link |
| Light source | Pulsed red laser diode |
| Wave length | 670 nm |
| Laser class | 1 |
| Light indicator | LED yellow |
| IO-Link | Yes |
| Interface | IO-Link V1.1 |
| Switching frequency | 5000 Hz , default2000 Hz 1000 Hz 10000 Hz |
| Voltage supply range +Vs | 10 ... 30 VDC |
| Current consumption max. (no load) | 30 mA |
| Output function | Light / dark operate switchable |
| Output circuit | Push-pull / IO-Link |
| Voltage drop Vd | < 2.8 VDC |
| Output current | < 200 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 144 mm |
| Fork width Sb | 120 mm |
| Height / length | 90 mm |
| Penetration depth | 60 mm |
| Depth | 12 mm |
| Type | U profile |
| Housing material | Die-cast zinc |
| Connection types | Connector M8, 3 pin |
| Operating temperature | -25В ...В +60 В°C |
| Protection class | IP 67 |
