Baumer OR18.EL-NV1P.7BCV
Through beam sensors - standard
We ship to United States of America!
art. 11157820
- receiver
- through beam sensor
- 55 m
- NPN complementary
- potentiometer, 270°
- cable 4 pin, 2 m
- -10 ... 55 °C
- IP 67
Item Number:
OR18.EL-NV1P.7BCV
Delivery standard: 3-6 weeks, depending on the country.
Condition: new
The price and delivery terms is not final. Please check with the manager.
Contact our experts
- Overview +
- Comments +
| Baumer Article no | 11157820 |
| Type | Through beam sensor |
| Emitter / receiver | Receiver |
| Actual range Sb | 55 m |
| Nominal range Sn | 60 m |
| Output indicator | LED yellow |
| Power on indication | LED green |
| Sensitivity adjustment | Potentiometer, 270В° |
| Response time / release time | < 0.34 ms |
| Voltage supply range +Vs | 10 ... 30 VDC |
| Current consumption max. (no load) | 45 mA |
| Current consumption typ. | 35 mA |
| Voltage drop Vd | < 2 VDC |
| Output function | Light / dark operate |
| Output circuit | NPN complementary |
| Output current | < 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 18 mm |
| Height / length | 77 mm |
| Type | Cylindrical threaded |
| Housing material | Brass nickel plated |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -10В ...В +55 В°C |
| Protection class | IP 67 |
