Endress+Hauser 6BABL4-BSDACADSAGA1K+AADADHPBPE

Flowmeter

T-mass B150 flush-mounted version is suitable for large pipes or rectangular ventilation ducts. It is designed for cost-effective measurement of household gases, particularly compressed air. It is intended for flow monitoring at lower distribution levels. The device features a robust, compact aluminum housing and a 4-wire circuit. User settings are stored in the display module and can be transferred from one device to another via this module.

Datasheet:

• Sensor Features: HistoROM Module / Dynamic Temperature Compensation / Selectable up to 4 measured gases 1 totalizer
• Transmitter Features: Quick and efficient installation – manual and operating menu / High availability – self-diagnostics and fault monitoring  / Automatic data retrieval for maintenance
• Nominal Diameter: Range DN 80…1500
• Clamping ring: PEEK 450G
• Measured parameters: Mass flow, temperature, corrected volume flow, volume flow with ambient air supply
• Max. measurement error: By mass: +/- 3.0%
• Measuring range: Dependent on process conditions and the measured gas
• Max. operating pressure: -0.5… 20 barg
• Product temperature range: -40… +100°C
• Ambient temperature range: –40… +60°C
• Transducer housing material: AlSi10Mg, coated
• Metrological standards and certificates: Calibrated on certified calibration equipment (compliant with ISO/IEC 17025), NAMUR

Wetted Materials:

• Transmitter: 1.4404 (316L)
• Insertion Pipe: 1.4404 (316L); 1.4435 (316L)
• Connection: Compression Fitting: 1.4404 (316L)
• O-Ring: EPDM; HNBR; 1.4401 (316)
