Endress+Hauser 7F2C50-AABEJEADAAED2SKA1+PM
Vortex flowmeter

Endress+Hauser 7F2C50-AABEJEADAAED2SKA1+PM

Vortex flowmeter

  • Measuring range: 0.1 kg/s - 400 kg/s (0.22 lb/s - 882 lb/s)
  • Accuracy: ±0.75% of the reading
  • Protection class: IP67
  • Operating temperature: -200°C…+400°C/-328°F…+750°F
Item Number: 7F2C50-AABEJEADAAED2SKA1+PM
4213.00
-
+
Total price: 4213.00
The price is not final. Please check with the manager!
Contact our experts
  • Overview
  • Comments

Endress+Hauser 7F2C50-AABEJEADAAED2SKA1+PM

The Endress+Hauser 7F2C50-AABEJEADAAED2SKA1+PM is a robust and versatile flowmeter specifically designed for measuring steam mass flow in demanding industrial applications. It combines advanced sensor technology with a user-friendly remote display for accurate and reliable measurement under harsh conditions.

Datasheet:

  • TSP Catalog Code: 7F2C50-AABEJEADAAED2SKA1
  • Marking material: AA (for non-explosive areas)
  • Output / input: B (4-20 mA HART, pulse / frequency / switching output)
  • Indication / control: E (SD03 4-line, backlit; touch control + data backup function)
  • Housing: J (GT20 two-section, aluminum, coated, remote)
  • Cable, remote version: E (30 m/90 ft)
  • Electrical connection: A (cable gland M20)
  • Sensor type; DSC sensor; measuring tube: DA (mass vapor; 316L; 316L (integrated pressure/temperature measurement), -200°C...+400°C/-328°F...+750°F)
  • Sensor seals DSK: A (graphite, -200°C...+400°C, -328°F...752°F)
  • Pressure component: E (piezometric element 40 bar/580 psi abs.)
  • Process connection: D2S (PN40, flange EN1092-1-B1)
  • Calibration flow: K (0.75% volumetric 3-point)
  • Instrument model: A1 (1)
  • Accessories included: PM (sensor holder (pipe mount) DN20-DN80 3/4"-3")

Benefits:

  • Improved accuracy and reliability: Ensures accurate steam flow measurement for optimized process control and cost savings.
  • Reduced installation and maintenance costs: Eliminates the need for separate pressure and temperature sensors, simplifying installation and maintenance.
  • Enhanced operator convenience: Remote display provides easy access to measurement data and simplifies operation.
  • Versatility and flexibility: Wide range of configurations and approvals make it suitable for diverse applications.
