Endress+Hauser Cleanfit H CPA475
Retractable assembly
Retractable assembly for measuring pH and ORP
- Overview +
- Comments +
Sterilizable retractable pH-ORP measuring assembly.
Measuring principleSensor ORP / Redox
ApplicationFood, pharmaceuticals, process
InstallationRetractable holder
CharacteristicOpen and closed tank, piping (min. DN80)
Design- hygienic style- manual or pneumatic, can be fully automated with CPC30 / 300.- integrated rinse chamber (Z-shape) with connection G1/4" or NPT1/4".
MaterialHolder : stainless steel 1.4435Sealing : different materials (FDA) available.
DimensionImmersion deepth : 48 - 102mm
Process temperaturemax. 80 bzw. 140В°C
Process pressuremax. 4/6 bzw. 10bar
ConnectionDN25 thread adapter nut, Triclamp, Varivent, APV, dairy fitting DN50, flange DN50/PN10, flange ASME 2"/150lbs
Additional certifications- 3.1.B EN 10204- 3A / EHEDG (inline steam sterilisability+cleanability)
Measuring principleAmperometric oxygen measurement
ApplicationFood, pharmaceuticals, process
Characteristic- Retractable holder- Open and closed tank, piping (min. DN80)
Design- hygienic style- manual or pneumatic, can be fully automated with CPC30 / 300.- integrated rinse chamber (Z-shape) with connection G1/4" or NPT1/4".
MaterialHolder : stainless steel 1.4435Sealing : different materials (FDA) available.
DimensionImmersion depth : 48 - 102mm
(1.87inch -3.97inch)
max. 80 or 140В°C
(176В°F or 284В°F)
max. 4/6 or 10bar
(58psi/87psi or 145psi)
DN25 thread adapter nut, Triclamp, Varivent, APV, dairy fitting DN50, flange DN50/PN10, flange ASME 2"/150lbs
Additional certifications- 3.1.B EN 10204- 3A / EHEDG (inline steam sterilisability+cleanability)
Measuring principlePotentiometric
ApplicationFood, pharmaceuticals, process
InstallationRetractable assembly
CharacteristicOpen and closed tank, piping (min. DN80)
Design- hygienic style - manual or pneumatic, can be fully automated with CPC30 / 310 - integrated rinse chamber (Z-shape) with connection G1/4" or NPT1/4".
MaterialHolder: stainless steel 1.4435Sealing : different materials (FDA) available.
DimensionImmersion depth: 48 - 102mm
(1.87 inch -3.97 inch)
max. 80 or 140В°C
(176В°F or 284В°F)
max. 4/6 or 10 bar
(58 psi/87 psi or 145 psi)
DN25 thread adapter nut, Triclamp, Varivent, APV, dairy fitting DN50, process connection DN50/PN10, process connection ASME 2"/150 lbs
Additional certifications- 3.1.B EN 10204- 3A / EHEDG (inline steam sterilisability + cleanability)
Buy Endress+Hauser Cleanfit H CPA475 with the best possible price and delivery terms on eltra-trade.com
eltra-trade.com is an online electrical store. Our product range includes industrial sensors, motor control components, pneumatic automation, and many other automation equipment. You can receive your order in any country in the world. By providing you with minimum prices, you can save money. You don't need to pay in advance if you are our regular customer. We respect your needs and are interested in their total satisfaction.
