Endress+Hauser FMB53-AA21JA1HGD15B3U+AAPO

Hydrostatic Level measurement Deltapilot FMB53

The Deltapilot FMB53 is a hydrostatic level transmitter designed for accurate level measurement in liquids and paste-like media. It features a Contite measuring cell, which is condensate-resistant, making it suitable for various process engineering, pharmaceutical, and food industry applications.

Datasheet:

• Measuring Principle: Hydrostatic pressure measurement
• Measuring Range: 0.1 to 10 bar (1.5 to 150 psi)
• Process Temperature Range: -10 to +70 °C (14 to 158 °F) with PE cable, -10 to +80 °C (14 to 176 °F) with FEP cable
• Max. Process Pressure: 40 bar (600 psi)
• Wetted Materials: Liner: 316L, Alloy C22, Rhodium-Gold, PE/FEP cable, optional coating AuPt or AuRh
• Outputs: 4-20 mA HART (active/passive), Pulse/frequency/switch output, Modbus RS485, 4-20 mA
• Digital Communication: HART, MODBUS RS485
• Power Supply: 2-wire loop powered
• Hazardous Area Approvals: ATEX, IECEx, cCSAus, EAC, NEPSI, INMETRO, KC, JPN, UK Ex
• Degree of Protection: IP66/67, Type 4X enclosure
• Additional Features: Bluetooth wireless technology for remote operation, Heartbeat Technology for verification without process interruption

Advantages:

• High Accuracy: Very good reproducibility and long-term stability.
• Condensate-Resistant: The Contite measuring cell ensures reliable operation even in condensate-prone environments.
• Wide Temperature Range: Suitable for a variety of process temperatures.
• Ease of Installation: Simple, fast commissioning through a user interface designed for real-world applications.
• Remote Operation: Bluetooth wireless technology for easy commissioning, operation, and maintenance.
• Safety: Certified for use in SIL2 safety systems.
• International Approvals: Wide range of international approvals for global use.
