Endress+Hauser Proline Prowirl F 200 / 7F2B
Vortex flowmeter
- Overview +
- Comments +
Vortex
Product headlineThe flowmeter with detection of wet steam conditions, available as compact or remote version.
Integrated temperature measurement for mass/energy flow of saturated steam.
Suitable for a wide range of applications; optimized for steam applications.
Highest process safety dualsens version enables redundant measurement. High availability proven robustness, resistance to vibrations, temperature shocks & water hammer. No maintenance lifetime calibration.
Wet steam detection and measurement for DN 25 to 100 (1 to 4"). Inlet run compensation. Face-to-face length according to industry standard.
Convenient device wiring separate connection compartment. Safe operation no need to open the device due to display with touch control, background lighting. Integrated verification Heartbeat Technology.
Display module with data transfer function. Robust dual-compartment housing. Plant safety: worldwide approvals (SIL, Haz. area).
DN 15 to 300 (ВЅ to 12")
Wetted materialsMeasuring tube: 1.4408 (C3FM); CX2MW similar to Alloy C22, 2.4602
DSC sensor: 1.4435 (316/316L); UNS N06022 similar to Alloy C22, 2.4602
Connection: 1.4404 (F316/F316L); CX2MW similar to Alloy C22, 2.4602; 1.4408 (CF3M)
Volume flow, mass flow, corrected volume flow, energy flow, heat flow difference, temperature
Max. measurement errorVolume flow (liquid): В±0.75 %
Volume flow (steam, gas): В±1.00 %
Mass flow (liquid): В±0.85%
Mass flow (steam, gas): В±1.7 %
Liquid: 0.16 to 2412 mВі/h (0.09 to 1420 ftВі/min)
depending on medium: water with 1 bar a, 20 В°C (14.5 psi a, 68В° F)
Steam, gas: 2 to 32 166 mВі/h (1.18 to 18 932 ftВі/min)
depending on medium: steam with 180 В°C, 10 bar a (356 В°F, 145 psi a); air with 25 В°C, 4.4 bar a (77 В°F, 63.8 psi a)
PN 40, Class 300, 20K
Medium temperature rangeStandard: 40 to +260 В°C (40 to +500 В°F)
High/low temperature (option): 200 to +400 В°C (328 to +752 В°F)
High/low temperature (on request): 200 to +450 В°C (328 to +842 В°F)
Compact version (standard): 40 to +80 В°C (40 to +176 В°F)
Compact version (option): 50 to +80 В°C (58 to +176 В°F)
Remote version (standard): 40 to +85 В°C (40 to +185 В°F)
Remote version (option): 50 to +85 В°C (58 to +185 В°F)
Sensor connection housing: AlSi10Mg, coated; 1.4408 (CF3M)
Transmitter housing materialAlSi10Mg, coated; 1.4404 (316L)
Degree of protectionCompact version: IP66/67, type 4X enclosure
Sensor remote version: IP66/67, type 4X enclosure
Transmitter remote version: IP66/67, type 4X enclosure
4...line backlit display with touch control (operation from outside)
Configuration via local display and operating tools possible
Remote display available
4...20 mA HART (passive)
4...20 mA (passive)
Pulse/frequency/switch output (passive)
Current Input 4...20 mA (passive)
Digital communicationHART, PROFIBUS PA, FOUNDATION Fieldbus
Power supplyDC 12 to 35 V (4...20 mA HART with/without pulse/frequency/switch output)
DC 12 to 30 V (4...20 mA HART, 4...20 mA)
DC 12 to 35 V (4...20 mA HART, pulse/frequency/switch output, 4...20 mA input)
DC 9 to 32 V (PROFIBUS PA, pulse/frequency/switch output)
ATEX, IECEx, cCSAus, EAC
Other approvals and certificatesFunctional safetyFunctional safety according to IEC 61508, applicable in safety-relevant applications in accordance with IEC 61511
Metrological approvals and certificatesCalibration performed on accredited calibration facilities (acc. to ISO/IEC 17025)
Heartbeat Technology complies with the requirements for measurement traceability according to ISO 9001:2015 Section 7.1.5.2 a (TГњV SГњD attestation)
PED, CRN, AD 2000
Material certificates3.1 material
NACE MR0175/MR0103, PMI (on request); welding test acc. to ISO 15614...1, similar to ASME IX (on request)
Vortex
Product headlineThe flowmeter with detection of wet steam conditions, available as compact or remote version.
Integrated temperature measurement for mass/energy flow of saturated steam.
Suitable for a wide range of applications; optimized for steam applications.
Highest process safety dualsens version enables redundant measurement. High availability proven robustness, resistance to vibrations, temperature shocks & water hammer. No maintenance lifetime calibration.
Wet steam detection and measurement for DN 25 to 100 (1 to 4"). Inlet run compensation. Face-to-face length according to industry standard.
Convenient device wiring separate connection compartment. Safe operation no need to open the device due to display with touch control, background lighting. Integrated verification Heartbeat Technology.
Display module with data transfer function. Robust dual-compartment housing. Plant safety: worldwide approvals (SIL, Haz. area).
DN 15 to 300 (ВЅ to 12")
Wetted materialsMeasuring tube: 1.4408 (C3FM); CX2MW similar to Alloy C22, 2.4602
DSC sensor: 1.4435 (316/316L); UNS N06022 similar to Alloy C22, 2.4602
Connection: 1.4404 (F316/F316L); CX2MW similar to Alloy C22, 2.4602; 1.4408 (CF3M)
Volume flow, mass flow, corrected volume flow, energy flow, heat flow difference, temperature
Max. measurement errorVolume flow (liquid): В±0.75 %
Volume flow (steam, gas): В±1.00 %
Mass flow (liquid): В±0.85%
Mass flow (steam, gas): В±1.7 %
Liquid: 0.16 to 2412 mВі/h (0.09 to 1420 ftВі/min)
depending on medium: water with 1 bar a, 20 В°C (14.5 psi a, 68В° F)
Steam, gas: 2 to 32 166 mВі/h (1.18 to 18 932 ftВі/min)
depending on medium: steam with 180 В°C, 10 bar a (356 В°F, 145 psi a); air with 25 В°C, 4.4 bar a (77 В°F, 63.8 psi a)
PN 40, Class 300, 20K
Medium temperature rangeStandard: 40 to +260 В°C (40 to +500 В°F)
High/low temperature (option): 200 to +400 В°C (328 to +752 В°F)
High/low temperature (on request): 200 to +450 В°C (328 to +842 В°F)
Compact version (standard): 40 to +80 В°C (40 to +176 В°F)
Compact version (option): 50 to +80 В°C (58 to +176 В°F)
Remote version (standard): 40 to +85 В°C (40 to +185 В°F)
Remote version (option): 50 to +85 В°C (58 to +185 В°F)
Sensor connection housing: AlSi10Mg, coated; 1.4408 (CF3M)
Transmitter housing materialAlSi10Mg, coated; 1.4404 (316L)
Degree of protectionCompact version: IP66/67, type 4X enclosure
Sensor remote version: IP66/67, type 4X enclosure
Transmitter remote version: IP66/67, type 4X enclosure
4...line backlit display with touch control (operation from outside)
Configuration via local display and operating tools possible
Remote display available
4...20 mA HART (passive)
4...20 mA (passive)
Pulse/frequency/switch output (passive)
Current input 4...20 mA (passive)
Digital communicationHART, PROFIBUS PA, FOUNDATION Fieldbus
Power supplyDC 12 to 35 V (4...20 mA HART with/without pulse/frequency/switch output)
DC 12 to 30 V (4...20 mA HART, 4...20 mA)
DC 12 to 35 V (4...20 mA HART, pulse/frequency/switch output, 4...20 mA input)
DC 9 to 32 V (PROFIBUS PA, pulse/frequency/switch output)
ATEX, IECEx, cCSAus, EAC
Other approvals and certificatesFunctional safetyFunctional safety according to IEC 61508, applicable in safety-relevant applications in accordance with IEC 61511
Metrological approvals and certificatesCalibration performed on accredited calibration facilities (acc. to ISO/IEC 17025)
Heartbeat Technology complies with the requirements for measurement traceability according to ISO 9001:2015 Section 7.1.5.2 a (TГњV SГњD attestation)
PED, CRN, AD 2000
Material certificates3.1 material
NACE MR0175/MR0103, PMI (on request); welding test acc. to ISO 15614...1, similar to ASME IX (on request)
Vortex
Product headlineThe flowmeter with detection of wet steam conditions, available as compact or remote version.
Integrated temperature measurement for mass/energy flow of saturated steam.
Suitable for a wide range of applications; optimized for steam applications.
Highest process safety dualsens version enables redundant measurement. High availability proven robustness, resistance to vibrations, temperature shocks & water hammer. No maintenance lifetime calibration.
Wet steam detection and measurement for DN 25 to 100 (1 to 4"). Inlet run compensation. Face-to-face length according to industry standard.
Convenient device wiring separate connection compartment. Safe operation no need to open the device due to display with touch control, background lighting. Integrated verification Heartbeat Technology.
Display module with data transfer function. Robust dual-compartment housing. Plant safety: worldwide approvals (SIL, Haz. area).
DN 15 to 300 (ВЅ to 12")
Wetted materialsMeasuring tube: 1.4408 (C3FM); CX2MW similar to Alloy C22, 2.4602
DSC sensor: 1.4435 (316/316L); UNS N06022 similar to Alloy C22, 2.4602
Connection: 1.4404 (F316/F316L); CX2MW similar to Alloy C22, 2.4602; 1.4408 (CF3M)
Volume flow, mass flow, corrected volume flow, energy flow, heat flow difference, temperature
Max. measurement errorVolume flow (liquid): В±0.75 %
Volume flow (steam, gas): В±1.00 %
Mass flow (liquid): В±0.85%
Mass flow (steam,, gas): В±1.7 %
Liquid: 0.16 to 2412 mВі/h (0.09 to 1420 ftВі/min)
depending on medium: water with 1 bar a, 20 В°C (14.5 psi a, 68В° F)
Steam, gas: 2 to 32 166 mВі/h (1.18 to 18 932 ftВі/min)
depending on medium: steam with 180 В°C, 10 bar a (356 В°F, 145 psi a); air with 25 В°C, 4.4 bar a (77 В°F, 63.8 psi a)
PN 40, Class 300, 20K
Medium temperature rangeStandard: 40 to +260 В°C (40 to +500 В°F)
High/low temperature (option): 200 to +400 В°C (328 to +752 В°F)
High/low temperature (on request): 200 to +450 В°C (328 to +842 В°F)
Compact version (standard): 40 to +80 В°C (40 to +176 В°F)
Compact version (option): 50 to +80 В°C (58 to +176 В°F)
Remote version (standard): 40 to +85 В°C (40 to +185 В°F)
Remote version (option): 50 to +85 В°C (58 to +185 В°F)
Sensor connection housing: AlSi10Mg, coated; 1.4408 (CF3M)
Transmitter housing materialAlSi10Mg, coated; 1.4404 (316L)
Degree of protectionCompact version: IP66/67, type 4X enclosure
Sensor remote version: IP66/67, type 4X enclosure
Transmitter remote version: IP66/67, type 4X enclosure
4...line backlit display with touch control (operation from outside)
Configuration via local display and operating tools possible
Remote display available
4...20 mA HART (passive)
4...20 mA (passive)
Pulse/frequency/switch output (passive)
Current input 4...20 mA (passive)
Digital communicationHART, PROFIBUS PA, FOUNDATION Fieldbus
Power supplyDC 12 to 35 V (4...20 mA HART with/without pulse/frequency/switch output)
DC 12 to 30 V (4...20 mA HART, 4...20 mA)
DC 12 to 35 V (4...20 mA HART, pulse/frequency/switch output, 4...20 mA input)
DC 9 to 32 V (PROFIBUS PA, pulse/frequency/switch output)
ATEX, IECEx, cCSAus, EAC
Functional safetyFunctional safety according to IEC 61508, applicable in safety-relevant applications in accordance with IEC 61511
Metrological approvals and certificatesCalibration performed on accredited calibration facilities (acc. to ISO/IEC 17025)
Heartbeat Technology complies with the requirements for measurement traceability according to ISO 9001:2015 Section 7.1.5.2 a (TГњV SГњD attestation)
PED, CRN, AD 2000
Material certificates3.1 material
NACE MR0175/MR0103, PMI (on request); welding test acc. to ISO 15614...1, similar to ASME IX (on request)
