Endress+Hauser FTC625

Transmitter

Measuring principle

Conductive

Characteristic / Application

Transmitter with intrinsically safe signal
Calibration using operating keys
Permanent self monitoring, setting via push-buttons
adjustable operating delay
2-wire PFM
RS232, RS485 interface
Rail mounting: 45mm

Specialities

Min / Max - changeover
Self-monitoring:
High operational safety in connection with EC27 / FTI51 / FTI52
Remote control via Fieldgate (Internet)
May be operated using ToF Tool

Supply / Communication

85V ... 253V AC
20V ... 60V DC

Ambient temperature

Serial montage
-20 В°C ... 50 В°C
(-4 В°F ... 122 В°F)

Communication

2 Relays
RS485

Certificates / Approvals

ATEX
FM
CSA
TISS
WHG/ Overfill prevention

Measuring principle

Capacitive Solid

Characteristic / Application

Transmitter with intrinsically safe signal
Calibration using operating keys
Permanent self monitoring, setting via push-buttons
adjustable operating delay
2-wire PFM
RS232, RS485 interface
Rail mounting: 45mm

Specialities

Self-monitoring:
High operational safety in connection with EC27
Remote control via Fieldgate (Internet)
May be operated using ToF Tool

Supply / Communication

85V ... 253V AC
20V ... 60V DC

Ambient temperature

-20 В°C ... 50 В°C Serial montage
(-4 В°F ... 122 В°F)

Communication

2 Relay
RS485

Certificates / Approvals

ATEX
FM
CSA
TIIS
WHG
