IFM Electronic ID3507 Inductive sensor
Item Number: ID3507
- Inductive sensor
- Sensing range 60 mm non-flush mountable
- Operating voltage 20...250 AC/DC V
- 2-wire
- 7/8" Connector
- Overview
- Datasheet
- Alternative numbers
- Comments
| Switch frequency (Hz), DC | 4 Hz |
| Link | 7/8" Connector |
| Technical code | IDE2060-FBOA/NPT/LS300L RT |
| Code | ID3507 |
| Working voltage, AC | 20...250 V |
| Working voltage, DC | 20...250 V |
| Assembly | non-flush mountable |
| Voltage category | AC/DC |
| Level of protection | IP 65 |
| Display type | switching status: 1 x LED red |
| Switch frequency (Hz), AC | 4 Hz |
| Degree of protection | I |
| Used materials | PPE |
| SKU | M8JV639PNFJKEY |
| sensitivity range | 60 mm |
| Temperature of surroundings | -25...80 В°C |
