IFM Electronic OGT500 Cylindrical diffuse reflection sensor
Item Number: OGT500
Diffuse reflection sensor, Threaded type, M18 x 1, DC PNP, Electronic lock, Teach function, Connector
- Overview
- Datasheet
- Alternative numbers
- Comments
| Lens material: | PMMA |
| Connection: | M12 connector |
| Protection: | IP 67 |
| Operating voltage: | 10...36 V DC |
| Length: | 72 mm |
| Electrical design: | DC PNP |
| Ambient temperature: | -25...80 °C |
| Output function: | light-on / dark-on programmable |
| Product Name: | OGT500 |
| Switching frequency: | 2000 Hz |
| Housing materials: | stainless steel 316L / 1.4404, PA, LCP, EPDM, TPU |
| Shortcode: | OGT-FPKG/US100 |
| Range: | 2...800 (Range referred to white paper 200 x 200 mm, 90 % remission) mm |
| Type of light: | Red light 624 nm |
| Current rating: | 150, 200 (...60 °C) mA |
| SKU | 3BEGH79LG1FLQ9 |
| Output status indication: | LED yellow |
