Pepperl+Fuchs NBB15-U1-A2 Inductive sensor

Pepperl+Fuchs NBB15-U1-A2
Item Number: NBB15-U1-A2
Series: VariKont ®, Housing material: PA/metal with epoxy powder coating, Rated operating distance: 15 mm, Connection type: screw terminals, Output type: 4-wire, Installation: flush, Type of voltage: DC
128.10
Quantity
-
+
Total price: 128.10
Contact our experts
  • Overview
  • Datasheet
  • Alternative numbers
  • PDF
  • Comments
General specifications
Switching element functionPNP NO/NC
Rated operating distance15 mm
Installationflush
Output polarityDC
Assured operating distance0 ... 12.15 mm
Reduction factor rAl 0.33
Reduction factor rCu 0.3
Reduction factor r304 0.74
Reduction factor rBrass 0.41
Nominal ratings
Operating voltage10 ... 30 V
Switching frequency0 ... 200 Hz
Hysteresistyp. 5 %
Reverse polarity protectionreverse polarity protected
Short-circuit protectionpulsing
Voltage dropless than or equal to 2 V
Operating current0 ... 200 mA
Off-state current0 ... 0.5 mA
No-load supply currentless than or equal to 20 mA
Operating voltage indicatorLED, green
Switching state indicatorLED, yellow
Functional safety related parameters
MTTFd1230 a
Mission Time (TM)20 a
Diagnostic Coverage (DC)0 %
Approvals and certificates
UL approvalcULus Listed, General Purpose
CSA approvalcCSAus Listed, General Purpose
CCC approvalCCC approval / marking not required for products rated less than or equal to 36 V
Ambient conditions
Ambient temperature-25 ... 85 °C (-13 ... 185 °F)
Mechanical specifications
Connection typescrew terminals
Core cross-sectionmax. 2.5 mm2
Housing materialPA/metal with epoxy powder coating
Sensing facePA
Degree of protectionIP68 / IP69K
Mass225 g
NoteTightening torque: 1.8 Nm (housing)
Tightening torque: 1.0 Nm (Screw terminal)
