Pepperl+Fuchs NBB15-U1-E2
Inductive sensor
IN STOCK!!!
- art. 194767
- Sensor head bidirectional and rotatable
- 15 mm flush
- 4 LEDs indicator for 360° visibility
- Overview +
- Comments +
IN STOCK!!!
The Pepperl+Fuchs NBB15-U1-E2 (Order Code: 194767) is a versatile inductive proximity sensor from the renowned VariKont® series. Designed for flexibility, this sensor features a rotatable sensing head that can be adjusted in 5 directions, making it ideal for applications with complex mounting requirements.
This cubic sensor offers a 15 mm flush sensing range and a reliable PNP Normally Open (NO) output. Unlike standard cylindrical sensors, the NBB15-U1-E2 utilizes a terminal compartment with screw terminals, allowing for direct wiring without the need for pre-assembled connectors.
Key Features:
- VariKont Housing: 40 x 40 mm standard industrial design.
- Rotatable Head: Sensing face can be oriented up, down, left, right, or front without moving the base.
- Easy Maintenance: 4 LEDs provide 360° visibility of power and switching status.
- Robust Connection: Dedicated terminal compartment (screw terminals) for secure cable installation.
Replacement & Accessories Info
- Alternative for: Replaces older VariKont models with specific mounting bases.
- Recommended Accessories: Modular mounting bracket MHW 01 (Adjustable holder).
Frequently Asked Questions" (FAQ)
- Q: What is the difference between NBB15-U1-E2 and NBB20-U1-E2?
- A: The NBB15 is a flush mount sensor with a 15mm range, while the NBB20 is non-flush with a longer 20mm range.
- Q: How do I wire the NBB15-U1-E2?
- A: This sensor uses a screw terminal chamber. Pin 1 is typically V+ (10-30V), Pin 3 is 0V (GND), and Pin 4 is the PNP Output. Always refer to the wiring diagram on the housing.
Datasheet:
| Switching element function | PNP | |
| Rated operating distance | 15 mm | |
| Installation | flush | |
| Output polarity | DC | |
| Assured operating distance | 0 ... 12.15 mm | |
| Reduction factor rAl | 0.33 | |
| Reduction factor rCu | 0.31 | |
| Reduction factor r304 | 0.74 | |
| Reduction factor rBrass | 0.41 | |
| Nominal ratings | ||
| Operating voltage | 10 ... 30 V | |
| Switching frequency | 0 ... 200 Hz | |
| Hysteresis | typ. 5 % | |
| Reverse polarity protection | reverse polarity protected | |
| Short-circuit protection | pulsing | |
| Voltage drop | less than or equal to 2 V | |
| Operating current | 0 ... 200 mA | |
| Off-state current | 0 ... 0.5 mA typ. 0.01 mA | |
| No-load supply current | less than or equal to 20 mA | |
| Operating voltage indicator | LED, green | |
| Switching state indicator | LED, yellow | |
| Functional safety related parameters | ||
| MTTFd | 1460 a | |
| Mission Time (TM) | 20 a | |
| Diagnostic Coverage (DC) | 0 % | |
| Approvals and certificates | ||
| UL approval | cULus Listed, General Purpose | |
| CSA approval | cCSAus Listed, General Purpose | |
| CCC approval | CCC approval / marking not required for products rated less than or equal to 36 V | |
| Ambient conditions | ||
| Ambient temperature | -25 ... 85 °C (-13 ... 185 °F) | |
| Mechanical specifications | ||
| Connection type | screw terminals | |
| Core cross-section | less than or equal to 2.5 mm2 | |
| Housing material | PA/metal with epoxy powder coating | |
| Sensing face | PA | |
| Degree of protection | IP68 / IP69K | |
| Mass | 225 g | |
| Note | Tightening torque: 1.8 Nm (housing) Tightening torque: 1.0 Nm (Screw terminal) | |
