Pepperl+Fuchs WTS10-12/20/105
Diffuse mode sensor
We ship to United States of America!
- Specifically for quality checks on welding caps
- Upper and lower welding caps checked simultaneously
- High position and angle tolerance insensitivity of the welding cap
- Pre-fault indication
- Scratch resistant mineral glass lens
Item Number:
WTS10-12/20/105
The price is not final. Please check with the manager!
Contact our experts
- Overview
- Comments
| Degree of protection | IP67 |
| Function indicator | LED yellow: switching state LED red: Pre-fault indication |
| Mass | 80 g |
| Switching type | light on |
| Switching frequency | 100 Hz |
| Light source | LED |
| Ambient light limit | continuous light 40000 Lux , Modulated light 5000 Lux |
| Teach-In indicator | LED, green/yellow flashing (approx. 4 Hz) Teach Error:LED green/yellow non equiphase flashing; 8.0 Hz |
| Switching current | max. 100 mA |
| Response time | 5 ms |
| Operating voltage | 10 ... 30 V DC |
| UL approval | cULus Listed |
| Light type | modulated visible red light , 640 nm |
| Ambient temperature | 0 ... 50 В°C (32 ... 122 В°F) The switching accuracy will remain, if the temperature after Teach-In does not varies more than В±7 В°C |
| Protection class | II, rated voltage 250 V AC with pollution degree 1-2 according to IEC 60664-1 |
| Connection | 5-pin, M12 x 1 connector |
| Position tolerance | В± 2 mm |
| No-load supply current | 70 mA |
| Operation indicator | LED green: Power on |
| Signal output | 2 switch outputs PNP, NO short-circuit protected reverse polarity protected |
| Reference target | Copper welding-electrode Diameter: 16 mm , Front end: 6 mm |
| Control elements | Teach-In key |
| CCC approval | CCC approval / marking not required for products rated 36 V |
| Detection range | 2 ... 12 mm |
| Tilting angle | В± 1.5 В° |
| Storage temperature | -20 ... 70 В°C (-4 ... 158 В°F) |
