Sick WTB12-3P2411
Photoelectric Sensor
IN STOCK!!!
- art. 1041422
- Series W12-3
- Sensing range: 20 mm ... 600 mm
- Overview +
- Comments +
IN STOCK!!!
Sick Photoelectric proximity sensor with background suppression WTB12-3P2411 (art. 1041422) in compact size.
Thanks to modern technology, precise background suppression is ensured. The sensor can also withstand harsh operating conditions. Equipped with PinPoint LED technology with a highly visible light spot. Options with IR LED are available for critical applications
Datasheet:
| Part Number | 1041422 |
| Power consumption: | ≤ 55 mA |
| Output current Imax.: | 100 mA |
| Switching mode: | Light/dark switching |
| Connection type: | Connector M12, 4-pin |
| Switching frequency: | 1,500 Hz |
| Protection class: | II |
| Output function: | Complementary |
| Adjustment: | Potentiometer, 5 turns |
| Weight: | 120 g |
| Ambient operating temperature: | -40 °C ... 60 °C |
| Housing material: | Metal |
| Response time: | ≤ 330 µs |
| Signal voltage PNP HIGH / LOW: | > Uv - 2,5 V / ca. 0 V |
| Light source: | LED |
| Sensing range: | 20 mm ... 600 mm |
| Enclosure rating: | IP 66 IP 67 IP 69K |
| Dimensions (W x H x D): | 15.6 mm x 48.5 mm x 42 mm |
| Ripple: | ≤ 5 Vpp |
| UL File No.: | NRKH.E181493 & NRKH7.E181493 |
| Ambient storage temperature: | -40 °C ... 75 °C |
| Switching output: | PNP |
| Wave length: | 850 nm |
| Type of light: | Infrared light |
| Supply voltage: | 10 V DC ... 30 V DC |
| Circuit protection: | A, C, D |
| Light spot size (distance): | 15 x 15 mm (200 mm) |
| Sensor/detection principle: | Photoelectric proximity sensor, Background suppression |
| Housing design (light emission): | Rectangular |
| Sensing range max.: | 20 mm ... 600 mm |
