Siemens 6ES7134-6GF00-0AA1

SIMATIC ET 200SP Analog input module

The Analog Input Module (AIN) is a key subsystem in the PLC. AINs come in many variations to condition real world physical parameters, such as, Temperature, Pressure, Force, or Strain. Typically, these AIN inputs are command signals in both voltage (e.g. ±10V) and current form (e.g. 4-20mA).

Siemens signal modules are designed to build an I/O system for analog signals of SIMATIC S7-300 programmable controllers and SIMATIC ET 200M distributed I/O stations.
The use of signal modules allows the controller to be optimally adapted to the requirements of the task being solved. The required number and type of analog inputs and outputs is ensured by selecting the appropriate number of signal modules of certain types.
Using these modules, it is possible to measure and form high-resolution analog values, as well as to connect a wide range of analog sensors and actuators.

6es71346gf000aa1 Datasheet:

• Group: Simatic ET 200SP
• Type: AI 8XI 2-/4-WIRE Basic
• Installation: on base unite A0 / A1
• Max. current consumption: 25 mA (without sensor power supply)
• Module diagnostics
• Color: CC01
• 16 BIT
• Possibility of updating the firmware
• Functional standard HW: not lower than FS04
• Sensor supply: 24V, Short circuit protection
• Max. output current: 0.7 A (Total current of all sensors/channels)
• Normal power dissipation: 0.7 W (without encoder supply voltage)
• Max. address space per module: 16 byte
• Mechanical coding element Type A
• Number of analog inputs: 8 / asymmetric
• Max. permissible input current for the current input (limit destruction): 50 mA
• Min. cycle time (all channels): 1 ms/per channel
• Shielded wire length, max.: 200 m
• Dimensions(WxHxD), mm: 15x73x58
• Weight, approx.: 31g

134 6gf00 0aa1 Characteristics:
