Siemens 6ES7215-1AG40-0XB0

Compact CPU 1215C

IN STOCK!!!

6ES72151AG400XB0 Siemens S7 1200 CPU 1215C DC DC DC,  compact  type with 2 PROFINET ports and power supply DC 20.4 - 28.8V DC. Program/data memory -  125 KB

6ES7215-1AG40-0XB0 is a member of the new family of Siemens microcontrollers for a wide variety of low-level automation tasks. These controllers are modular and versatile. They are able to work in real time, can be used to build relatively simple nodes of local automation or nodes of complex automatic control systems that support intensive communication data exchange via Industrial Ethernet / PROFINET networks, as well as PtP (Point-to-Point) connections.
S7 1200 1215c programmable controllers have compact IP20 plastic housings, can be mounted on a standard 35 mm DIN rail or on a mounting plate, and operate in a temperature range from 0 to +50 °C.

They are capable of servicing from 10 to 284 discrete and from 2 to 51 analog I/O channels. With the same I/O configurations as the S7-200, the S7-1200 controller takes up 35% less installation volume.

Communication modules (CM) can be connected to the central processing unit (CPU) of the S7-1200 programmable controller; signal modules (SM) and signal boards (SB) for input/output of digital and analog signals. Together with them, a 4-channel Industrial Ethernet switch (CSM 1277) and a power supply module (PM 1207) are used.

• Product Number Siemens 6ES7215-1AG40-0XB0
• Product Code 85371091
• Device Life Stage Active
• Item Package Size (cm) 11,50 x 13,50 x 8,50
• Item Net Weight 0,446 Kg
• Product Price Group 212
• Siemens Device Catalog Chapter ST72
• Device family 6ES7215
• Item SKU TATC8WEY
• Item Group № 4509

All Siemens CPUs offer high performance and support a wide range of functions:

• Programming in LAD and FBD languages, an exhaustive set of commands.
• High performance (the execution time of a logical operation does not exceed 0.1 µs).
• Non-volatile memory with a capacity of 2 KB for unattended data storage during power failures of the controller.
• Built-in digital inputs for universal use, allowing you to enter potential or pulse signals.
• Built-in real-time hardware clock with 240-hour power reserve in case of power failure.
• Built-in downloadable memory up to 2 MB, expandable with memory card up to 24 MB.
• Built-in high-speed counters with input frequency up to 100 kHz.
• Built-in pulse outputs with a pulse repetition rate up to 100 kHz (only in CPUs with transistor outputs).
• Working memory up to 50 KB.
• Support for PID control functions.
• Support for operating system update functions.
• Password protection of the user program.
• Support for motion control functions in accordance with the requirements of the PLCopen standard.
• Freely programmable ports for communication with other devices on the CM 1241 communication modules.

Contact our managers to get The Best 6ES7215 1AG40 0XB0 price! We have full catalog of Siemens cpu.
