Siemens 6SL3210-1KE11-8AF2

Frequency drive

IN STOCK!!!

Frequency converter 6SL3210-1KE11-8AF2 apply as a speed controller in standard use of house automation, which is a great power performance regulator for equipment working. SINAMICS G120 frequency inverter from Siemens is an easy and cost-effective device for these request.

Supply voltage is three-phase 380 V ± 10%, power range from 0.55 to 132 kW.
Control modes - vector control, V/f, V/f ECO. The drive has 6 digital and 1 analog inputs, as well as 2 digital and 1 analog output.

6SL32101KE118AF2 main Features :

• Simple installation and assembly - fixing on the wall or directly in the through channel;
• Ability to use a USB port to connect a flash drive or computer;
• Easy to operate and program the system;
• Support for the newest and easy-to-use USS, Modbus RTU interface;
• Two types of user settings IOP and VOR-2;

This device applying in such areas as pumps, radial fans, belt conveyors, individual drives in processing industries, basic movement drives in apparatus with mechanically connected axles.

Siemens 6sl3210 1ke11 8af2 Datasheet:

• Family: SINAMICS G120C
• Power: 0,55KW
• Frequency: 47...63HZ
• Filter Class A, Integrated
• 3AC380... 480V +10/-20%
• I/O-INTERFACE: 6DI,2DO,1AI,1AO
• Integrated Fieldbus, PROFINET-PN
• External: 24V
• Protection Class: IP20
• LO rated current: 2,30 A
• HO rated current: 1,90 A
• Size: FSAA
• 173x73x178(HXWXD)

Specifications:
