ABB ACS800-01 Wall-Mounted Single Drives

Frequency converter

ACS800-01-0011-5+L501+L503+P901 Pcont.max:7,5kW, Icont.max:13,2A

Frequency converter

Frequency converter

Wall-mounted 6-pulse drive

Pcont.max:75kW
Icont.max:145A

ACS800-01-0140-5 Pcont.max:110kW, Icont.max:180A

Wall-mounted single drive

Wall-mounted single drive

Frequency Converter

  • ACS800-01-0040-3 Pcont.max:37kW, Icont.max:72A
TypeSERVICE SUITCASE
Weight14 kg
TypeSERVICE SUITCASE-EXPERT
Weight0.001 kg
  • ACS800-01-0205-3 Pcont.max:160kW, Icont.max:290A
Output Current5.1 A
Output Power1.1 kW
TypeFrequency Converter
Weight9 kg
Output Current6.5 A
Output Power2.2 kW
TypeFrequency Converter
Weight9 kg
Output Current4.9 A
Output Power2.2 kW
TypeFrequency Converter
Weight9 kg
Output Current13.9 A
Output Power3 kW
TypeFrequency Converter
Weight9 kg
Output Current8.5 A
Output Power3 kW
TypeFrequency Converter
Weight9 kg
Output Current10.9 A
Output Power4 kW
TypeFrequency Converter
Weight9 kg
Output Current8.1 A
Output Power4 kW
TypeFrequency Converter
Weight9 kg
Output Current13.9 A
Output Power5.5 kW
TypeFrequency Converter
Weight9 kg
Output Current10.5 A
Output Power5.5 kW
TypeFrequency Converter
Weight9 kg

Frequency Converter ACS800-01-0011-3 with 48 … 63 Hz, 19 A, 7.5 kW

Output Current13.2 A
Output Power7.5 kW
TypeFrequency Converter
Weight9 kg
Output Current13 A
Output Power11 kW
TypeFrequency Converter
Weight26 kg
Output Current25 A
Output Power11 kW
TypeFrequency Converter
Weight14 kg
Output Current19 A
Output Power11 kW
TypeFrequency Converter
Weight14 kg
Output Current34 A
Output Power15 kW
TypeFrequency Converter
Weight14 kg
Output Current44 A
Output Power22 kW
TypeFrequency Converter
Weight26 kg

ACS800-01

The line of ABB ACS800 01 drives has power spectrum 0,55 - 110 kW and belongs to single drives of wall mounting. One of their distinctive properties is small size. All important functions are built-in in the ACS 800-01 drives, and their enclosure meets the all important needs of customers.

Also an additional options is included in one single drive, such as EMC filter, choke, brake chopper and others. Converters protection is IP 55 or IP 21.

All this allows to apply this series of drives in different fields of industry.

Besides standard this model of drives is approved for marine application because of operating readiness and increased reliability in marine condition.


Benefits of ACS800-01 drives:
- good encoder options;
- flexible input-output;
- easy access to drive settings due to control panel;
- DTC (Direct Torque Control) in standard kitting;
- build-in EMC filter;
- support of large spectrum of fieldbus protocols.

ACS800-11

ACS800-11 series is belonging to regenerative single drives of wall-mounting, which are equipped with active rectifier. It allowed creating a full-featured regenerative drive in one compact unit. All important functions and additional equipment are inbuilt in drive, including the network LCL filter and filter EMC. Range of nominal powers is from 5,5 to 110 kW. Class of protection is IP21.

The presence of the regenerative modules in ACS800-11 drives allows substantially reducing the power consumption of a process plant with high inertial loads, returning energy in a network at braking.

The distinctive feature of drives of this series is DTC method of engine control (Direct Torque Control), which allows which allows to obtain excellent characteristics of asynchronous motors control at low speeds (the accuracy of torque control and speeds) without the use of feed-back sensors. It is possible to connect the motor encoder to drive for better performance.
