Baumer Ultrasonic Sensors
art. 10148822
- UNAM 18I6903/S14 withcurrent output
- 100 ... 1000 mm
- -10 ... +60 °C
art. 10157539
| scanning range sd | 40 ... 400 mm |
| scanning range far limit Sde | 60 ... 400 mm |
| hysteresis typ. | 4 % Sde |
| output circuit | NPN make function (NO) |
| operating temperature | -10 ... +60 °C |
art. 10232784
| scanning range sd | 100 ... 1000 mm |
| scanning range far limit Sde | 100 ... 1000 mm |
| hysteresis typ. | 4 % Sde |
| output circuit | PNP break function (NC) |
| operating temperature | -10 ... +60 °C |
art. 10125522
Ultrasonic distance sensors
- Wide measuring range
- High measurement accuracy
- Wide range of operating temperatures
- Resistance to dirt and vibrations
art. 10131958
Ultrasonic sensors UZDK 30N6112/S14
- Extended working distance
- Extended temperature range
- Extended operating voltage range
- Functional safety
- Robust construction
art. 10118863
Contact Form: Double Pole, Single Throw (DPST)
Type: DC
Sensing Type: Proximity Style
Compatible Mounting Type: Surface Mount
Shield: Unshielded
Sensor Type: Solid State
Termination Type: Connector
art. 10234440
| emitter / receiver | receiver |
| scanning range sd | 0 ... 700 mm |
| scanning range far limit Sde | 0 ... 700 mm |
| output circuit | PNP complementary |
| operating temperature | 0 ... +60 °C |
art. 10140060
| scanning range sd | 10 ... 200 mm |
| scanning range far limit Sde | 30 ... 200 mm |
| hysteresis typ. | 4 % Sde |
| output circuit | PNP make function (NO) |
| operating temperature | -10 ... +60 °C |
art. 10149127
| scanning range sd | 100 ... 1000 mm |
| scanning range close limit Sdc | 100 ... 1000 mm |
| scanning range far limit Sde | 100 ... 1000 mm |
| output circuit | voltage output |
| operating temperature | -10 ... +60 °C |
art. 10134142
| scanning range sd | 400 ... 2500 mm |
| scanning range close limit Sdc | 400 ... 2500 mm |
| scanning range far limit Sde | 400 ... 2500 mm |
| output circuit | current output |
| operating temperature | -10 ... +60 °C |
art. 10129530
| scanning range sd | 400 ... 2500 mm |
| scanning range close limit Sdc | 400 ... 2500 mm |
| scanning range far limit Sde | 400 ... 2500 mm |
| output circuit | current output |
| operating temperature | -10 ... +60 °C |
art. 10130405
| scanning range sd | 350 ... 2500 mm |
| scanning range far limit Sde | 350 ... 2500 mm |
| hysteresis typ. | 4 % Sde |
| output circuit | NPN make function (NO) |
| operating temperature | -25 ... +60 °C |
art. 10156679
| scanning range sd | 400 ... 2500 mm |
| scanning range close limit Sdc | 400 ... 2500 mm |
| scanning range far limit Sde | 400 ... 2500 mm |
| output circuit | voltage output |
| operating temperature | -10 ... +60 °C |
art. 10131880
| scanning range sd | 400 ... 2500 mm |
| scanning range close limit Sdc | 400 ... 2500 mm |
| scanning range far limit Sde | 400 ... 2500 mm |
| output circuit | voltage output |
| operating temperature | -10 ... +60 °C |
art. 10162125
| special type | chemically resistant |
| scanning range sd | 60 ... 400 mm |
| scanning range close limit Sdc | 60 ... 400 mm |
| output circuit | current output |
| operating temperature | 0 ... +60 °C |
art. 10161023
| special type | chemically resistant |
| scanning range sd | 100 ... 1000 mm |
| scanning range far limit Sde | 100 ... 1000 mm |
| output circuit | NPN make function (NO) |
| operating temperature | 0 ... +60 °C |
art. 10161024
| special type | chemically resistant |
| scanning range sd | 100 ... 1000 mm |
| scanning range far limit Sde | 100 ... 1000 mm |
| output circuit | NPN break function (NC) |
| operating temperature | 0 ... +60 °C |
art. 10160414
| special type | chemically resistant |
| scanning range sd | 100 ... 1000 mm |
| scanning range close limit Sdc | 100 ... 1000 mm |
| output circuit | voltage output |
| operating temperature | 0 ... +60 °C |
art. 10155042
| scanning range sd | 60 ... 400 mm |
| scanning range close limit Sdc | 60 ... 400 mm |
| scanning range far limit Sde | 60 ... 400 mm |
| output circuit | current output |
| operating temperature | -10 ... +60 °C |
art. 10142491
| scanning range sd | 10 ... 200 mm |
| scanning range far limit Sde | 30 ... 200 mm |
| hysteresis typ. | 4 % Sde |
| output circuit | PNP break function (NC) |
| operating temperature | -10 ... +60 °C |
art. 10158275
| scanning range sd | 100 ... 1000 mm |
| scanning range close limit Sdc | 100 ... 1000 mm |
| scanning range far limit Sde | 100 ... 1000 mm |
| output circuit | voltage output |
| operating temperature | -10 ... +60 °C |
art. 10146711
| scanning range sd | 20 ... 200 mm |
| scanning range close limit Sdc | 20 ... 200 mm |
| scanning range far limit Sde | 20 ... 200 mm |
| output circuit | voltage output |
| operating temperature | -10 ... +60 °C |
art. 10129046
| scanning range sd | 100 ... 1000 mm |
| scanning range close limit Sdc | 100 ... 1000 mm |
| scanning range far limit Sde | 100 ... 1000 mm |
| output circuit | current output |
| operating temperature | -10 ... +60 °C |
art. 10123379
| scanning range sd | 30 ... 250 mm |
| scanning range far limit Sde | 30 ... 250 mm |
| hysteresis typ. | 4 % Sde |
| output circuit | PNP break function (NC) |
| operating temperature | -25 ... +60 °C |
art.10234439
- emitter
- scanning range sd: 0 ... 700 mm
- operating temperature: 0 ... +60 °C
art. 10131013
| special type | 2 point proximity switch |
| scanning range sd | 350 ... 2500 mm |
| scanning range far limit Sde | 350 ... 2500 mm |
| output circuit | NPN make function (NO) |
| operating temperature | -10 ... +60 °C |
art. 10129063
| special type | 2 point proximity switch |
| scanning range sd | 350 ... 2500 mm |
| scanning range far limit Sde | 350 ... 2500 mm |
| output circuit | NPN make function (NO) |
| operating temperature | -10 ... +60 °C |
art. 11121235
| scanning range sd | 2 ... 82 mm |
| scanning range close limit Sdc | 2 ... 82 mm |
| scanning range far limit Sde | 2 ... 82 mm |
| output circuit | current output |
| operating temperature | -10 ... +60 °C |
art. 10145833
| scanning range sd | 5 ... 70 mm |
| scanning range far limit Sde | 5 ... 70 mm |
| hysteresis typ. | 4 % Sde |
| output circuit | PNP make function (NO) |
| operating temperature | 0 ... +60 °C |
art. 11099365
| special type | 2 point proximity switch |
| scanning range sd | 600 ... 6000 mm |
| scanning range far limit Sde | 600 ... 6000 mm |
| output circuit | PNP make function (NO) / break function (NC) |
| operating temperature | -25 ... +60 °C |
Ultrasonic sensors determine the position of an object using an ultrasonic signal.
Baumer produces the following types of ultrasonic sensors:
- Miniature
- Robust with flexible parameterization
- With teach button
- With large sensing distances
- High-speed sensors
- With sonic nozzles
- Chemically robust
- With IO-Link
The products manufactured by the German company divided into two main categories: Ultrasonic Proximity and Distance sensors.
Proximity sensors have several operating principles depending on the models. Proximity switches are the simplest model. It consists of a converter and a receiver integrated in one housing. Retro-reflective sensors works the same way with any sound-reflecting object. Through-beam sensors have two separate housings with a transmitter and receiver.
Distance sensors measure the distance to an object without contact. The devices have an internal potentiometer. It allows a user to set the output resolution. The company produces models with built-in D / a- converter. Long-cable devices are available to count EMI or RFI interference.
In addition to the main series, the company also manufactures accessories for them. Optional equipment includes connectors / pin assignment, mounting accessories and kits SENSOFIX.
Baumer hubner ultrasonic sensors are capable of accurate non-contact measurements even in the most polluted environments.
More detailed information you can see here:
- Baumer ultrasonic sensor manual pdf (EN)
- Baumer capteur de distance à ultrason pdf (français) (FR)
- Baumer ultraschallsensor abstandsmessung katalog pdf (DE)
