Data interface

Input

USB signal as per USB specification.

Output

Connects HART field devices with the USB interface of a laptop

Data interface

Configuration of Endress+Hauser devices.

Ground ring

Mounting kit

Input

12 analog (max) (U, I, TC, RTD, frequency, pulse)
6 digital (max)

Output

6 relays (max)
1 transmitter power supply

Display

TFT 5.7" colour graphic display

Power supply

100...230 V AC +/-10%
24V (-10%, +15%) AC/DC

Storage/Recording

Internal memory
SD card
USB flash drive

Storage/Recording

internal memory
SD card
USB flash drive

Input

1x Puls/Analog
2x RTD/Analog
Loop power supply 24V DC (+/-16%)

Output

1x 4...20mA
2x digital (Open Collector)

Display

160 x 80 Dot-Matrix LCD with white backlit
colour change in case of alarm event
active display area 70 x 34 mm

Calculations

heat quantity and heat quantity difference

Input

1x Puls/Analog for flow
2x RTD/Analog for temperature and pressure
Loop power supply 24V DC (+/-16%)

Output

1x 4...20mA
2x digital (Open Collector)

Display

160 x 80 Dot-Matrix LCD with white backlit
colour change in case of alarm event
active display area 70 x 34 mm

Calculations

IAPWS-IF97

Reporting software for data management and visualization (Single-station license).

Reporting software for data management and visualization (Multi-user license).

Input

Camera:
5 MP camera on the back with auto focus and LED flash with 1500 mcd
2 MP camera on the front
Scanner:
1D/2D barcode scanner

Field process indicator

Input

Foundation Fieldbus protocol
PROFIBUS PA protocol

Output

Not defined

Display

High contrast backlit LCD with bargraph
TAG/unit

Power Supply

Not defined

Gateway for remote monitoring

Input

4x 4...20 mA analog
4x digital
Pulse counter
Modbus TCP
Modbus RS485

Output

4x digital
Modbus TCP
Modbus RS485

Gateway for remote monitoring

Output

WirelessHART and/or BluetoothВ® communication interface,
Operating frequency: 2.4 GHz (ISM band),
Transmission range under reference conditions:
WirelessHART communication - up to 200 m (656 ft),
Bluetooth communication - up to 40 m (131 ft)

Field process indicator

Input

Foundation Fieldbus protocol
PROFIBUS PA protocol

Output

Not defined

Display

High contrast backlit LCD with bargraph
TAG/unit

Power Supply

Not defined

Data interface

Delay barrier

Input

1 x analog 4...20 mA

Output

1 x analog 4...20 mA

Surge arrester for DIN rail according to IEC 60715.

Surge arresters for field mounting.

Registrar

Field gateway for tank sensor operation, monitoring and integration into inventory control system.

Input

Enraf BPM; Saab TRL/2

Output

Modbus RS485
