Baumer FHDM 16N5001 Diffuse sensors with background suppression

Baumer FHDM 16N5001
Item Number: FHDM 16N5001
typebackground suppression
light sourcepulsed red LED
sensing distance Tw20 ... 450 mm
operating temperature-25 ... +65 °C
237.82
Quantity
-
+
Total price: 237.82
Contact our experts
  • Overview
  • Datasheet
  • Alternative numbers
  • PDF
  • Comments
output current< 200 mA
response time / release time< 1 ms
current consumption max. (no load)41 mA
sensing distance adjustmentmechanical, 5 turn
output circuitNPN
sensing range Tb (at Tw max.)20 ... 450 mm
operating temperature-25 ... +65 °C
short circuit protectionyes
light indicatorLED yellow
height / length50 mm
front (optics)PMMA
width / diameter15,4 mm
typerectangular
protection classIP 67
typebackground suppression
light sourcepulsed red LED
reverse polarity protectionyes
current consumption typ.29 mA
sensing distance Tw20 ... 450 mm
connection typescable 4 pin, 2 m
voltage drop Vd< 1,8 VDC
voltage supply range +Vs10 ... 30 VDC
wave length660 nm
output functionlight / dark operate
housing materialdie-cast zinc
manufacter SKUFHDM 16N5001
suppression of reciprocal influenceyes
depth50 mm
sensing range Tb (at Tw min.)5 ... 20 mm
