Baumer FHDM 16N5004 Diffuse sensors with background suppression

Baumer FHDM 16N5004
Item Number: FHDM 16N5004
type background suppression
light sourcepulsed red LED
sensing distance Tw20 ... 600 mm
operating temperature-25 ... +65 °C
237.82
Quantity
-
+
Total price: 237.82
Contact our experts
  • Overview
  • Datasheet
  • Alternative numbers
  • PDF
  • Comments
housing material die-cast zinc
voltage drop Vd < 1,8 VDC
current consumption max. (no load) 41 mA
short circuit protection yes
manufacter SKUFHDM 16N5004
width / diameter 15,4 mm
light source pulsed red LED
wave length 660 nm
front (optics) PMMA
suppression of reciprocal influence yes
current consumption typ. 29 mA
connection types cable 4 pin, 2 m
voltage supply range +Vs 10 ... 30 VDC
sensing range Tb (at Tw min.) 5 ... 20 mm
response time / release time < 5 ms
sensing distance adjustment mechanical, 5 turn
output circuit NPN
light indicator LED yellow
sensing range Tb (at Tw max.) 20 ... 600 mm
type background suppression
depth 50 mm
protection class IP 67
reverse polarity protection yes
output current < 200 mA
type rectangular
operating temperature -25 ... +65 °C
height / length 50 mm
output function light / dark operate
sensing distance Tw 20 ... 600 mm
