Baumer FHDM 16N5004/S14 Diffuse sensors with background suppression

Baumer FHDM 16N5004/S14
Item Number: FHDM 16N5004/S14
type background suppression
light sourcepulsed red LED
sensing distance Tw20 ... 600 mm
operating temperature-25 ... +65 °C
237.82
Quantity
-
+
Total price: 237.82
Contact our experts
  • Overview
  • Datasheet
  • Alternative numbers
  • PDF
  • Comments
voltage drop Vd < 1,8 VDC
type rectangular
light source pulsed red LED
sensing range Tb (at Tw min.) 5 ... 20 mm
response time / release time < 5 ms
output circuit NPN
short circuit protection yes
current consumption max. (no load) 41 mA
housing material die-cast zinc
operating temperature -25 ... +65 °C
suppression of reciprocal influence yes
voltage supply range +Vs 10 ... 30 VDC
output current < 200 mA
sensing range Tb (at Tw max.) 20 ... 600 mm
output function light / dark operate
protection class IP 67
connection types connector M12 4 pin
wave length 660 nm
manufacter SKUFHDM 16N5004/S14
depth 50 mm
light indicator LED yellow
front (optics) PMMA
sensing distance Tw 20 ... 600 mm
width / diameter 15,4 mm
current consumption typ. 29 mA
type background suppression
sensing distance adjustment mechanical, 5 turn
reverse polarity protection yes
height / length 50 mm
