Baumer FLDM 180C1101/S42 Copy counters
Item Number: FLDM 180C1101/S42
| measuring distance Sd | 30 ... 50 mm |
| optimum operating distance | 40 mm |
| object speed | < 2 m/sec |
| output circuit | opto isolated |
| operating temperature | 10 ... +40 °C |
- Overview
- Datasheet
- Alternative numbers
- Comments
| housing material | aluminum / steel galvanized |
| front (optics) | glass |
| voltage supply range +Vs | 19 ... 30 VDC |
| connector base | Amphenol-Tuchel C91A T 3476 001,7 pin |
| object speed | < 2 m/sec |
| edge indicator | LED orange |
| manufacter SKU | FLDM 180C1101/S42 |
| sensitivity | single sheet/edge thickness 5 mm |
| sync. input | yes |
| width / diameter | 31 mm |
| current consumption max. (no load) | 200 mA |
| optimum operating distance | 40 mm |
| operating temperature | 10 ... +40 °C |
| measuring distance Sd | 30 ... 50 mm |
| output circuit | opto isolated |
| light source | pulsed infrared diode |
| power on indication | LED green |
| type | rectangular |
