Baumer FPDM 12N3401 Retro-reflective sensors

Baumer FPDM 12N3401
Item Number: FPDM 12N3401
type retro-reflective sensor
light sourcepulsed red LED
actual range Sb5 m
operating temperature-25 ... +65 °C
Price on Request
Quantity
-
+
Total price: 0.00
Contact our experts
  • Overview
  • Datasheet
  • Alternative numbers
  • PDF
  • Comments
manufacter SKUFPDM 12N3401
depth 35 mm
voltage supply range +Vs 10 ... 30 VDC
light indicator LED yellow
operating temperature -25 ... +65 °C
front (optics) PMMA
suppression of reciprocal influence yes
light source pulsed red LED
actual range Sb 5 m
housing material die-cast zinc
reverse polarity protection yes
type rectangular
protection class IP 67
polarization filter yes
connection types cable 4 pin, 2 m
width / diameter 12,4 mm
output current < 100 mA
type retro-reflective sensor
wave length 660 nm
height / length 35 mm
short circuit protection yes
current consumption max. (no load) 35 mA
output function alarm output dark
sensitivity adjustment no
alignment / soiled lens indicator flashing light indicator
current consumption typ. 25 mA
voltage drop Vd < 1,8 VDC
response time / release time < 1 ms
nominal range Sn 5,2 m
output circuit NPN
