Baumer O500.RR-GL1Z.72O Retro-reflective sensors
Item Number: O500.RR-GL1Z.72O
| type | retro-reflective sensor |
| light source | pulsed red LED |
| actual range Sb | 7,5 m |
| operating temperature | -25 ... +60 °C |
- Overview
- Datasheet
- Alternative numbers
- Comments
| current consumption typ. | 30 mA |
| wave length | 630 nm |
| connection types | connector M12 3 pin |
| light indicator | LED yellow |
| protection class | IP 67 |
| alignment optical axis | < 1° |
| voltage drop Vd | < 3 VDC |
| output current | < 100 mA |
| housing material | plastic (ASA, PMMA) |
| depth | 32 mm |
| short circuit protection | yes |
| front (optics) | PMMA |
| actual range Sb | 7,5 m |
| sensitivity adjustment | no |
| output function | light operate |
| output circuit | push-pull |
| type | rectangular |
| operating temperature | -25 ... +60 °C |
| current consumption max. (no load) | 40 mA |
| voltage supply range +Vs | 10 ... 30 VDC |
| suppression of reciprocal influence | yes |
| response time / release time | < 0,49 ms |
| power on indication | LED green |
| width / diameter | 18 mm |
| light source | pulsed red LED |
| reverse polarity protection | yes |
| polarization filter | yes |
| nominal range Sn | 8 m |
| manufacter SKU | O500.RR-GL1Z.72O |
| type | retro-reflective sensor |
| height / length | 45 mm |
