Baumer Encoders

Voltage supply	9...30 VDC 5 VDC ±5 % 9...26 VDC
Consumption w/o load	≤100 mA
Pulses per revolution	1024...10000
Operating temperature	-20...+85 °C

art. 11075575

POG10 DN 1024 I Solid shaft with a diameter of 11 mm. Flanges EURO B10. Increased shock and vibration protection. Encoder diameter 115 mm.

Number of pole pairs	1 = 2 poles
Transformation ratio	0.5 ±5 %
Phase shift	0° ±10°
Operating temperature	-20...+100 °C

Number of pole pairs	1 = 2 poles
Transformation ratio	0.5 ±5 %
Phase shift	0° ±10°
Operating temperature	-40...+100 °C

Number of pole pairs	1 = 2 poles
Transformation ratio	0.5 ±5 %
Phase shift	0° ±10°
Operating temperature	-40...+100 °C

Reversal tolerance	≤0.1 %
Linearity tolerance	≤0.15 %
Temperature coefficient	±0.05 %/K (open-circuit)
Operating temperature	-30...+130 °C

Reversal tolerance	≤0.1 %
Linearity tolerance	≤0.15 %
Temperature coefficient	±0.05 %/K (open-circuit)
Operating temperature	-30...+130 °C

Reversal tolerance	≤0.1 %
Linearity tolerance	≤0.15 %
Temperature coefficient	±0.05 %/K (open-circuit)
Operating temperature	-30...+130 °C

Reversal tolerance	≤0.1 %
Linearity tolerance	≤0.15 %
Temperature coefficient	±0.05 %/K (open-circuit)
Operating temperature	-30...+130 °C

Interference immunity	EN 61000-6-2
Emitted interference	EN 61000-6-3
Switching accuracy	±4 % (Δn = 2 rpm/s); = +20 % (Δn = 1500 rpm/s)
Operating temperature	-30...+130 °C

Reversal tolerance	≤0.1 %
Linearity tolerance	≤0.15 %
Temperature coefficient	±0.06 %/K (open-circuit)

Voltage supply	5 VDC ±5 % 8...26 VDC
Reverse polarity protection	Yes
Consumption w/o load	≤85 mA
Operating temperature	-20...+70 °C

Voltage supply	5 VDC ±5 % 8...26 VDC
Reverse polarity protection	Yes
Consumption w/o load	≤85 mA
Operating temperature	-20...+85 °C

Voltage supply	10...30 VDC
Reverse polarity protection	Yes
Consumption w/o load	≤50 mA (24 VDC)
Operating temperature	-25...+60 °C

Voltage supply	10...30 VDC
Reverse polarity protection	Yes
Consumption w/o load	≤100 mA (24 VDC)
Operating temperature	-25...+60 °C

Voltage supply	10...30 VDC 5 VDC ±10 %
Reverse polarity protection	Yes
Consumption w/o load	≤50 mA (24 VDC)
Operating temperature	-25...+60 °C
Inputs	SSI clock Control signals UP/DOWN and zero

art. 11034114

For cable transducers with cable thickness 0.8 - 1 mm

• Programming unit for HMG10P/PMG10P series
• Parametrization of SSI absolute signal, incremental output and speed switch (depending on encoder version)
• Monitoring of current position, speed und temperature
• Connection over Ethernet or wireless over WLAN
• Simple and intuitive use via webbrowser on pc, tablet or smartphone
• Fast parameter download

For cable transducers with cable thickness 0.8 - 1 mm
