Sensor head with magnetic tape for shaft 300...3183 mm

• Position resolution (Singleturn): up to 20 bits.
• Speed resolution: up to 18 bits.
• Output signals: SSI.
• Input for setting the zero position and selecting the direction of rotation.
• Status indication: via System OK output and LED.
• Large mounting tolerances.

art. 11033327

• Circumference: 50 cm / 0.5 m
• Hole: 7mm
• Outer Diameter: 159.15 ± 0.2 mm
• Cover profile: rubber handle with rubber crumb

og 71

• Encoder type: Incremental
• Detection method: Optical
• Body: aluminum
• Shaft: stainless steel
• Bearings: ball bearings
• Shaft diameter: 6 mm
• Shaft length: 15 mm
• Weight: 80 g

OG 8 Incremental encoder

• Solid shaft ø11 mm with EURO flange B10
• Optical sensing method
• EURO flange B10
• Output stage HTL or TTL
• Output stage TTL with regulator UB 9...26 VDC

The OG 9 from Baumer is an incremental encoder that is characterized by high reliability and accuracy. It is designed for use in heavy industry.

• Material: Housing - cast aluminum, shaft - stainless steel
• Operating temperature: -30...+100 °C (-25...+100 °C for >3072 pulses)
• Vibration resistance: IEC 60068-2-6 (10 g, 10-2000 Hz)
• Impact resistance: IEC 60068-2-27 (100 g, 6 ms)
• Corrosion protection: IEC 60068-2-52 (salt spray for C4 conditions according to ISO 12944-2)
• Explosion protection: II 3 G Ex ec IIC T4 Gc (gas), II 3 D Ex tc IIIB T135°C Dc (dust) (only with ATEX option)
• Weight: approx. 980 g

OG 90 incremental encoder

• Output signals: K1, K2, K0 + inverted
• Protection: IP 55
• Rotation speed: ≤12000 rpm
• Housing material: die-cast aluminum

og73

• Body materials: aluminum, powder coating
• Shaft materials: stainless steel
• Maximum rotation speed: up to 8000 rpm

• Incremental encoder (optionally programmable)
• HTL/TTL output driver for cable length up to 350 m
• Very high resistance to shock and vibrations
• Two-sided insulated bearing system with hybrid bearings
• Special protection against corrosion CX (C5-M)
• Large terminal box, turn by 180В°
• Function display via LEDs

pog 10

• TTL output driver for cable length up to 550 m
• High resistance to shock and vibrations
• EURO flange B10 / solid shaft ø11 mm
• Large terminal box, turn by 180°

Incremental encoders - combination

• TTL output driver for cable length up to 550 m
• Electronic speed monitoring
• EURO flange B10 / solid shaft ø11 mm
• Terminal boxes, turn by 180°

POG 10 + ESL 93

• TTL output driver for cable length up to 550 m
• EURO flange B10 / solid shaft ø11 mm
• Terminal boxes, turn by 180°

POG 10+ FSL is an incremental encoder

• Shaft type: ø11 mm solid shaft
• Permissible shaft load: ≤300 N axial, ≤450 N radial
• Temperature range: -40...+100 °C (optionally down to -50 °C)
• Protection: IP 66

art. 11042716

• art. 11042716
• POG10 DN 1024 I Solid shaft with a diameter of 11 mm.
• Flanges EURO B10.
• Increased shock and vibration protection.
• Encoder diameter 115 mm.

Incremental encoders - combination

• Twin encoder with two electrically separated systems
• TTL output driver for cable length up to 550 m
• EURO flange B10 / solid shaft ø11 mm

pog 11

• Size (flange): ø115 mm
• Shaft type: ø11 mm solid shaft
• Detection method: Optical
• Operating torque: 2 Ncm

• Mechanical speed monitoring based on centrifugal force
• Robust, compact housing
• Two bearings with large distance, one at each end
• High shaft load up to 350 N
• TTL output driver for cable length up to 550 m
• Terminal boxes, turn by 180В°

• Twin encoder featuring two separate systems
• Robust, compact housing
• Two bearings with large distance, one at each end
• High shaft load up to 350 N
• Shock resistant up to 300 g
• Highest operating speed 12000 rpm
• TTL output driver for cable length up to 550 m
• Terminal box, turn by 180В°

pog 9

• Housing material: Aluminum
• Shaft: Solid shaft ø11 mm
• Flange: EURO flange B10
• Moment of inertia: 100 g/cm²
• Maximum axial play: 0.2 mm
• Maximum radial play: 0.05 mm

Incremental encoders - combination

• TTL output driver for cable length up to 550 m
• Circuit breaker with one selectable threshold speed
• EURO flange B10 / solid shaft ø11 mm
• Terminal boxes, turn by 180°

Incremental encoders - combination

• TTL output driver for cable length up to 550 m
• Mechanical speed monitoring based on centrifugal force
• EURO flange B10 / solid shaft ø11 mm
• Terminal boxes, turn by 180°

pog 90

• Housing material: Aluminum
• Shaft material: Stainless steel
• Moment of inertia: 0.004 kgcm²
• Maximum axial play: 0.1 mm
• Maximum radial play: 0.05 mm
• Weight: 0.17 kg

art. 11076614

• art. 11076614

• 9-30 dc
• output signal format - htl / voltage output

art. 11076982

POG10G DN 1024 I / DN 1024 I Incremental encoders - combination

• Twin encoder, blind hollow shaft, 1024 pulses per revolution
• HTL output driver for cable length up to 350 m
• Very high resistance to shock and vibrations
• Double-side bearing with hybrid bearing for extended service life
• Large terminal box, turn by 180°

art. 11120547

Baumer PC Programming Tool Z

art. 11120547

RTD 1 B14 Y 1 Resolver

• Solid shaft ø6 mm with synchro flange
• Robust resolver with solid shaft ø6 mm
• Rotation speed max. 10000 rpm
• Centering alignment ø50 mm
• Mounting hole circle ø68 mm
• Wide operating temperature range

RTD 4 A 4 Y 2 Resolvers

• Blind hollow shaft ø10 to ø16 mm
• Robust resolver with blind hollow shaft ø10...16 mm
• Rotation speed max. 8000 rpm
• Very high resistance to shock and vibrations

S2BG connection cable

• Connection type: M23 connector, 12-pin
• Weight: Approximately 440 g (for 5 m cable), 860 g (for 10 m cable).

Tachogenerators

• Solid shaft ø6 mm with flange
• Open circuit voltage 10...60 mV per rpm
• Solid shaft ø6 mm with flange
• Very high resistance to shock

Baumer TDP 0.2

• Size (flange): ø115 mm
• Supply voltage: 10...150 mV/rev/min

TachogeneratorsTDP 13
