Baumer Encoders

Spring disk coupling K35 WD

• Permissible axial movement: ± 0.7 mm (±0.3 mm in the version with an insulated sleeve)
• Permissible parallel displacement: ± 0.2 mm (±0.05 mm in the version with an insulated sleeve)
• Permissible angular error: ± 1°
• Electrical isolation: Yes
• Weight: about 50 g
• Material of spring disks: X12 CrNi 17 7

Spring disk coupling K50 WD

• Permissible angular error: ± 1°
• Electrical isolation: No
• Weight: about 95 g
• Material of spring disks: X12 CrNi 17 71

Spring disk coupling K60 WD

• Permissible angular error: ± 1°
• Electrical isolation: No
• Weight: approximately 165 g
• Material of spring disks: X12 CrNi 17 7

KTD 2-1 B14

• Solid shaft ø6 mm with synchro flange
• Max. 10000 pulses per revolution
• Centering alignment ø50 mm, mounting screw hole circle ø68 mm
• TTL or HTL output signals

KTD 4-... A 4 Y10

• Size (flange): ø88 mm
• Shaft type: Ø20...27 mm (through hollow shaft)
• Protection EN 60529: IP 65

art. 10124973

Incremental encoderMA20

• With measuring arm and wheel
• Encoder with 16 predefined resolutions
• Max. 25000 pulses per revolution
• Measuring wheel circumference 200 mm
• Manual adjustment without any programming tool
• Different degrees of rubber hardness for optimal grip

MDFK 08

• Magnetic sensor with magnetic wheel
• Resolution max. 4096 steps
• Output signals A 90° B or A 90° B +N
• Output circuits: push-pull and RS422
• Non-contact, wear-free sensing system
• Narrow mounting design

MDFK 08 - RS422

• Magnetic sensor with magnetic wheel
• Resolution max. 4096 steps
• Output signals A 90° B or A 90° B +N
• Output circuits: push-pull and RS422

MDFK 08G2101 S35A

• Shaft type: ø6...43.5 mm (through hollow shaft)
• Protection EN 60529: IP 67
• Working distance: < 0.6 mm

MDFK 08G2101 S35A - Combination of sensor / magnetic wheel

Magnetic detector for rotary application

art. 10128137

art. 10166037

• Current output
• Flylead Connector PUR M8, L=200 mm
• -40 ... 85 В°C
• IP 67
• Please order magnet separately

art. 10166036

• Current output
• Cable PUR 3 x 0.25, 2 m
• -40 ... 85 В°C
• IP 67
• Please order magnet separately

art. 10166033

• Voltage output
• Cable PUR 3 x 0.25, 2 m
• -40 ... 85 В°C
• IP 67
• Please order magnet separately

• Leakage of parasetical shaft currents
• Blind hollow shaft Diam.16...30 mm

MHAD 50 - HDmag

• Absolute encoder, 1 or 2 sensing head
• Absolute encoder with magnetic sensing and without bearings
• Absolute resolution max. 16 bit singleturn
• Protection IP 67
• Large tolerances: axial ±1 mm, radial max. 1 mm

MHAP 100 - HDmag

• Absolute encoder
• Singleturn 8...17 Bit
• Magnetic sensing
• Through hollow shaft max. diam 80 mm

HDmag MHAP 200

• Sensor head: FPGA signal processing
• Type: Absolute encoder
• Resolution: 8...17 bits (single rotary)
• Maximum diameter of the hollow shaft: 180 mm

MHAP 400 - HDmag

• Absolute encoder with magnetic sensing and without bearings
• Sensor head with integrated FPGA signal processing
• Absolute resolution max. 17 bit singleturn
• Additional incremental output
• Electronics is fully encapsulated
• Large tolerances: axial ±1 mm, radial max. 0.5 mm
• Simple mounting, easy adaptation

HDmag MHGE 100 Encoders without bearings - incremental

• Robust and wearless
• High protection through fully encapsulated electronics
• Large tolerances: axial ±3 mm, radial max. 2.2 mm
• Very compact dimensions

• Robust and wearless
• High protection through fully encapsulated electronics
• Large tolerances: axial В±3 mm, radial max. 2.2 mm
• Very compact dimensions
• Simple mounting, easy adaptation

• Robust and wearless
• High protection through fully encapsulated electronics
• Large tolerances: axial В±3 mm, radial max. 2.2 mm
• Very compact dimensions
• Simple mounting, easy adaptation

HDmag MHGP 200 Encoders without bearings - incremental

• Sensor head with integrated FPGA signal processing / Magnetic sensing
• Robust and wearless
• Electronics is fully encapsulated, high protection
• Large tolerances: axial ±3 mm, radial max. 2.2 mm
• Very compact dimensions
• Simple mounting, easy adaptation
• Several mounting possibilities

MHGP 100 Encoders without bearings - incremental

• Axial tolerance: ±3 mm
• Radial tolerance: 0.1...2.2 mm
• Degree of protection: IP 67
• Operating temperature: -20...+85 °C
• Material: Housing - aluminum alloy, wheel - stainless steel

art. 10136428

• cable FEP, 2 m
• -40 ... 120 В°C

Baumer MIL10 linear incremental encoder without bearings

• Sensor head with magnetic tape
• Robust magnetic sensing method
• Output signals A 90° B with index signal
• Output circuits: HTL/push-pull and TTL/RS422
• Resolution up to 5 µm (4-times evaluation)
• Non-contact, wear-free sensing system
• High resistance to dirt and vibrations

MIR 3000F - HDmag flex

• HDmag flex MIR 3000F Encoders without bearings - incremental
• Sensor head with magnetic tape for shaft ø300...3185 mm
• Encoder without bearings - incremental with magnetic sensing
• Square-wave signals HTL/TTL or sine signals
• Max. 131072 pulses per revolution
• Status indication via system OK output and LED
• Fully encapsulated electronics IP 67

HDmag flex MIR 350A Encoders without bearings - incremental

• Sensor head with split wheel and magnetic tape for shaft ø90...300 mm
• Encoder without bearings - incremental with magnetic sensing
• Split wheel design for easiest mounting on installed shafts
• Very large axial tolerances ±8 mm
• Max. 131072 pulses per revolution
• Status indication via system OK output and LED
• Fully encapsulated electronics IP 67

mir10

• Reading method: Magnetic
• Short circuit protection: Yes
• Supply voltage: 10...30 VDC
• Reverse polarity protection: Yes
