Baumer Encoders

art. 11121870

Incremental encoder

• Voltage supply:4.75...30 VDC
• Operating temperature:-40...+100 °C
• Weight:300 g

art.11195401

• Precise optical sensing (interpolated)
• Output signal level programmable (TTL)
• Flange connector M23, 12-pin CW, radial
• Pulses per revolution 1...65536, programmable
• High protection IP 65

art. 11121852

• Precise optical sensing (interpolated)
• Output signal level programmable (TTL)
• Clamping flange
• Flange connector M23, 12-pin CCW, radial
• Pulses per revolution 1...65536, programmable

EIL580P-SQ10 Solid shaft with square flange

• Size ø58 mm
• Precise optical sensing (interpolated)
• Output signal level programmable (TTL or HTL)
• Square flange 2.5" (63.5 mm)

In stock!!!

Incremental encoder with synchro flange

• Size ø58 mm
• Precise optical sensing (interpolated)
• Output signal level programmable (TTL or HTL)
• Synchro flange
• Connection axial, radial or tangential
• Pulses per revolution 1...65536, programmable

Incremental encoder with through hollow shaft

• Size ø58 mm
• Precise optical sensing (interpolated)
• Output signal level programmable (TTL or HTL)
• Through hollow shaft, ø8…15 mm
• Connection radial or tangential

art. 11199462

• Size ø58 mm
• Precise optical sensing (interpolated)
• Through hollow shaft, ø12 mm
• Flange connector M23, 12-pin CCW, radial
• Pulses per revolution 1...65536, programmable
• High protection IP 65

incremental encoder EIL580P-TT

• Vibration resistance: 30 g, 10-2000 Hz (EN 60068-2-6)
• Impact resistance: 250 g, 6 ms (EN 60068-2-27)

art. 11121821

EIL580P-TT12.5FF.01024.B

• Size ø58 mm
• Precise optical sensing (interpolated)
• Output signal level programmable (TTL)
• Through hollow shaft, ø12 mm
• Flange connector M23, 12-pin CCW, radial
• Pulses per revolution 1...65536, programmable
• High protection IP 65

ExEIL580-B - blind hollow shaft

• Size ø58 mm
• Precise optical sensing (interpolated)
• Output signal level programmable (TTL or HTL)
• Blind hollow shaft, ø8…15 mm
• Connection axial, radial or tangential
• Pulses per revolution 1...65536, programmable

Baumer FOG 9

• Solid shaft ø10 mm or ø11 mm
• Compact, robust die-cast housing
• Flange connector with metal mating connector
• EURO flange B10

fog 9

• Power supply voltage: 9...30 V DC
• Current consumption: max. 50 mA
• Output signal: TTL with UB 9...30 VDC regulator; HTL with power line driver
• Maximum cable length: 100 m (TTL); 500 m (HTL)

FOG 9+GT 7.08

• Compact, robust die-cast housing
• Flange connector with metal mating connector
• EURO flange B10 / solid shaft ø11 mm

G 305

• Optical sensing method
• Up to 120 pulses with 1 or 2 pulse tracks
• Surface mount housing for measuring wheel

g0333

• Encoder with through hollow shaft ø12 mm
• Optical sensing method
• Max. 80000 pulses per revolution
• Clamping ring on housing

g0355

• Encoder with solid shaft ø10 mm or ø6 mm
• Max. 80000 pulses per revolution
• Industrial standard
• Clamping or synchro flange
• High rotation speed up to 10000 rpm
• Compact design
• High resistance to shock and vibrations

g0356

• Encoder with solid shaft ø10 mm or ø6 mm
• Max. 80000 pulses per revolution
• Industrial standard
• Clamping or synchro flange
• High rotation speed up to 10000 rpm
• Compact design
• High resistance to shock and vibrations

Baumer G0AMH

• Encoder singleturn / bus cover
• Optical sensing method
• Resolution: singleturn 13 bit
• Through hollow shaft up to ø14 mm
• CANopen®, EtherNet/IP, Profibus, PROFINET

G0M2H

• Reading method: Optical
• Hollow shaft diameter: up to 14 mm
• Supply voltage: 10...30 V DC
• No load consumption: ≤50mA (24VDC)
• Interface: SSI, additional incremental output (optional)
• Maximum rotation speed: 6000 rpm

G0MMH absolute encoder

• Relative humidity: 95 % without condensation
• Protection: IP 54, optionally IP 65
• Maximum rotation speed: ≤6000 rpm
• Housing material: aluminum
• Weight: approx. 600 g

G1I0

• Encoder with blind or through hollow shaft up to ø25.4 mm
• Max. 16384 pulses per revolution
• Optical sensing method
• Robust design

 GA210

Size (flange): Ø58 mm
Shaft type: Ø10 mm, solid shaft
Flange: Clamping flange

Interface: 10 parallel outputs
Function: Single-turn

ga240

• Encoder singleturn / parallel
• Optical sensing method
• Resolution: 13 bit
• Clamping flange
• Short-circuit proof push-pull outputs
• Output release by enable signal

ga240

• Encoder singleturn / SSI
• Optical sensing method
• Resolution: 14 bit
• Clamping flange

GBA2H absolute encoder

• Operating temperature: -25...+85 °C, -40...+85 °C (optional)
• Relative humidity: 95 % without condensation
• Resistance: EN 60068-2-6 Vibration ±0.75 mm - 10-58 Hz, 10 g - 58-2000 Hz, EN 60068-2-27 Impact 200 g, 6 ms
• Weight: approx. 400 g
• Connection: M23 connector, 12-pin, 1 m12 cable.

GBA2S absolute encoder

• Temperature range: -25 to +85 °C (optionally -40 to +85 °C)
• Degree of protection: IP 54, optional IP 65
• Weight: approx. 250 g

GBA2W is a solid shaft encoder available

• Detection method: Optical
• Resolution: Maximum 19 bits
• Flange: Clamp or synchronous
• Initialization time: Typically 20 ms after power on
• Optional incremental output: Available on request
• Zero point adjustment: Electronic
• Input of counting direction: Yes

GBAMS

• Measurement method: Optical
• Power supply voltage: 10...30 VDC
• Size (flange): ø58 mm
• Diagnostic function: Position or parameter error

GBM2H

• High resolution encoder multiturn / SSI
• Optical sensing method
• Resolution: singleturn 18 bit, multiturn 12 bit
• Through hollow shaft up to ø14 mm
• High reliability by self-diagnostics
• Counting direction input

GBMMW

• Encoder multiturn / bus cover
• Optical sensing method
• Total resolution up to 31 bit
• High resistance to shock and vibrations
