Baumer GXMMW A203EA2

Absolute Optical Encoder GXMMW A203EA2

Encoder multiturn / bus cover
Optical sensing method
Resolution: singleturn 13 bit, multiturn 16 bit
Clamping or synchro flange

Baumer GXMMW A203P32

GXMMW A203P32

Voltage supply 10...30 VDC
Reverse polarity protection Yes
Consumption w/o load ≤100 mA (24 VDC)
Operating temperature -25...+85 °C
-40...+85 °C (optional)

Baumer GXMMW.0203P33

GXMMW.0203P33

Resolution: singleturn 13 bit, multiturn 16 bit
Clamping or synchro flange
Interface: Profibus-DP
Code continuity check optional by bus
Maximum resistant against magnetic fields

Baumer gxmmw.a203p33

gxmmw.a203p33

Shaft diameter: 10 mm
Type of mounting: Clamping flange
Moment of inertia: 2.5e-7 kgm^2
Maximum acceleration speed: 10000 rpm^2
Response time: 1 μs
Power supply voltage: 10...30 V DC
Output signal: SSI, Profibus-DP, CANopen, EtherCAT

Baumer GXP1W - parallel

Solid shaft with clamping or synchro flange
Encoder multiturn / parallel
Optical sensing method
Resolution: singleturn 12 bit, multiturn 12 bit
RS232 encoder programming interface

Baumer GXP5S - CANopen®

Encoder multiturn / CANopen®
Optical sensing method
Resolution: singleturn 13 bit, multiturn 16 bit
Blind hollow shaft ø12...ø15 mm
LED status indicator

Baumer GXP5W - CANopen®

GXP5W - CANopen®

Solid shaft with clamping or synchro flange
Encoder multiturn / CANopen®
Optical sensing method
Resolution: singleturn 13 bit, multiturn 16 bit
Clamping or synchro flange
CANopen® Profile CIA DSP 406 / DSP 417 Lift

Baumer GXP6H - Interbus

Size (flange): ø58 mm
Shaft type: ø14 mm hollow shaft

Baumer GXP6W - Interbus

Size (flange): ø58 mm
Shaft type: ø14 mm hollow shaft

Baumer HEAG 150

Signal level shifting from HTL - TTL or TTL - HTL
Isolating signal cables to multiple receivers to avoid earth loops
Regenerating of signals when transmitting over long distance
1 input unit and 3 output units

Baumer HEAG 158

Converting of SinCos signals into TTL and HTL signals
Additional interpolation of the signals (multiplying or dividing)
Oversampling with 24 MHz
Digitally pre-filter
Very high output frequency possible

Baumer HEAG 159

Converting of SinCos signals into multiplied SinCos signals
Multiplying factor 1...128
Offset and amplitude adjustment
Oversampling with 24 MHz
Digitally pre-filter
High signal quality

Baumer HEAG 160

Converting of SinCos signals into multiplied SinCos signals
Additional interpolation of HTL or TTL signals (multiplying or dividing)
Oversampling with 24 MHz
Digitally pre-filter
Very high output frequency possible

Baumer HEAG 173, HEAG 174

Fiber-optic receiver for interference-free transmission of square-wave signals

For high interference locations
Each channel is coupled onto fiber-optic easy-to-fit plug
Reconversion of optical to electrical signals in the receiver control cabinet
3 different plug versions available
Delay time over a 100 m length of fiber-optic is 1 Вµs
Except of POF all fiber optic cable usable, e. g. PCF 200 Ојm, silica fiber 50 and 62.5 Ојm

Baumer HEK17

Test voltage: Wire/conductor: 1500 V ef, Wire/shield: 750 V ef
Protection: Common low-capacitance shield, shielded paired signal wires
Weight: Approximately 110 g/m

Baumer HG 16

Incremental encoder with optical sensing
Large axial and radial displacement of the shaft permitted
Fit for high operating speed
Robust and wearless
Max. 2048 pulses per revolution
Output stage TTL with regulator UB 9...26 VDC

Baumer HG 18

Incremental encoder with optical sensing
Fit for high operating speed
Max. 2500 pulses per revolution
Output stage TTL with regulator UB 9...26 VDC

Baumer HG 22

Incremental encoder with optical sensing
Robust and wearless
Max. 4000 pulses per revolution
Output stage TTL with regulator UB 9...26 VDC

Baumer HG16

The HG16 from Baumer is a bearingless incremental encoder

Operating temperature: -30...+100 °C
Vibration: 10 g, 10-2000 Hz
Impact: 100 g, 6 ms
Weight: approx. 2.4 kg
Connections: Terminal box or M23 flange connector, 12-pin

Baumer HG18

The Baumer HG18 is a bearingless incremental encoder

Operating temperature: -30...+70 °C
Vibration resistance: IEC 60068-2-6 (10 g, 10-2000 Hz)
Impact resistance: IEC 60068-2-27 (100 g, 6 ms)
Weight: approx. 4.2 kg
Connection: Terminal box or M23 flange connector, 12-pin.

Baumer HMC16

HMC16 is a bearingless incremental encoder

Protection: IP 68 (encoder), IP 65 (signal processing)
Material: aluminum alloy sensor head housing, stainless steel wheel (1.4104)
Operating temperature: encoder -20 to +85 °C, signal processing 0 to +50 °C
Vibration and shock resistance: vibration 25 g, 10-2000 Hz; shock 300 g, 12 ms12.

Baumer HMG 11

HMG 11

Multiturn / SSI / Profibus / CANopen® / DeviceNet / PROFINET
Optical sensing method
Singleturn 13 bit, multiturn 12 bit / 16 bit
Blind or through hollow shaft or cone shaft ø16...20 mm

Baumer HMG 161

HMG 161

Reading method: Optical
Size (flange): ø160 mm
Power supply voltage: 9...30 VDC
Function: Multiturn

Baumer HMG10-B - Incremental

Incremental encoder (optionally programmable)
HTL/TTL output driver for cable length up to 350 m
Very high resistance to shock and vibrations
Two-sided insulated bearing system with hybrid bearings
Special protection against corrosion CX (C5-M)
Large terminal box, turn by 180В°
Support plate for torque arm 360В° freely positionable
Mounting compatible with HOG10 encoders
Function display via LEDs

Baumer HMG10-T - PROFINET

Magnetic sensing method
Function display via LEDs
Multiturn sensing with Energy Harvesting technology "MicroGen", without gear or battery
Two-sided bearing system with hybrid bearings
Special protection against corrosion CX (C5-M)
