Baumer

baumer gxmmw

• Size (flange): ø58 mm
• Shaft type: ø10mm solid shaft (clamping flange), ø6mm solid shaft (synchronized flange)
• Flange: Clamping or synchronous flange
• Function: Multi-turn

GXMMW + incremental

• Size (flange): Ø58 mm.
• Code: Binary.
• Code sequence: CW/CCW programmable.
• Initial acceleration: ≤1000 U/s².

Absolute Optical Encoder GXMMW A203EA2

• Encoder multiturn / bus cover
• Optical sensing method
• Resolution: singleturn 13 bit, multiturn 16 bit
• Clamping or synchro flange

GXMMW A203P32

• Voltage supply 10...30 VDC
• Reverse polarity protection Yes
• Consumption w/o load ≤100 mA (24 VDC)
• Operating temperature -25...+85 °C
• -40...+85 °C (optional)

GXMMW.0203P33

• Resolution: singleturn 13 bit, multiturn 16 bit
• Clamping or synchro flange
• Interface: Profibus-DP
• Code continuity check optional by bus
• Maximum resistant against magnetic fields

gxmmw.a203p33

Shaft diameter: 10 mm
Type of mounting: Clamping flange
Moment of inertia: 2.5e-7 kgm^2
Maximum acceleration speed: 10000 rpm^2
Response time: 1 μs
Power supply voltage: 10...30 V DC
Output signal: SSI, Profibus-DP, CANopen, EtherCAT

Baumer GXP1W - parallel

• Solid shaft with clamping or synchro flange
• Encoder multiturn / parallel
• Optical sensing method
• Resolution: singleturn 12 bit, multiturn 12 bit
• RS232 encoder programming interface

Baumer GXP5S - CANopen®

• Encoder multiturn / CANopen®
• Optical sensing method
• Resolution: singleturn 13 bit, multiturn 16 bit
• Blind hollow shaft ø12...ø15 mm
• LED status indicator

GXP5W - CANopen®

• Solid shaft with clamping or synchro flange
• Encoder multiturn / CANopen®
• Optical sensing method
• Resolution: singleturn 13 bit, multiturn 16 bit
• Clamping or synchro flange
• CANopen® Profile CIA DSP 406 / DSP 417 Lift

Baumer GXP6H - Interbus

• Size (flange): ø58 mm
• Shaft type: ø14 mm hollow shaft

Baumer GXP6W - Interbus

• Size (flange): ø58 mm
• Shaft type: ø14 mm hollow shaft

• Signal level shifting from HTL - TTL or TTL - HTL
• Isolating signal cables to multiple receivers to avoid earth loops
• Regenerating of signals when transmitting over long distance
• 1 input unit and 3 output units

• Converting of SinCos signals into TTL and HTL signals
• Additional interpolation of the signals (multiplying or dividing)
• Oversampling with 24 MHz
• Digitally pre-filter
• Very high output frequency possible

• Converting of SinCos signals into multiplied SinCos signals
• Multiplying factor 1...128
• Offset and amplitude adjustment
• Oversampling with 24 MHz
• Digitally pre-filter
• High signal quality

• Converting of SinCos signals into multiplied SinCos signals
• Additional interpolation of HTL or TTL signals (multiplying or dividing)
• Oversampling with 24 MHz
• Digitally pre-filter
• Very high output frequency possible

Fiber-optic receiver for interference-free transmission of square-wave signals

• For high interference locations
• Each channel is coupled onto fiber-optic easy-to-fit plug
• Reconversion of optical to electrical signals in the receiver control cabinet
• 3 different plug versions available
• Delay time over a 100 m length of fiber-optic is 1 Вµs
• Except of POF all fiber optic cable usable, e. g. PCF 200 Ојm, silica fiber 50 and 62.5 Ојm

• Test voltage: Wire/conductor: 1500 V ef, Wire/shield: 750 V ef
• Protection: Common low-capacitance shield, shielded paired signal wires
• Weight: Approximately 110 g/m

Baumer HG 16

• Incremental encoder with optical sensing
• Large axial and radial displacement of the shaft permitted
• Fit for high operating speed
• Robust and wearless
• Max. 2048 pulses per revolution
• Output stage TTL with regulator UB 9...26 VDC

Baumer HG 18

• Incremental encoder with optical sensing
• Fit for high operating speed
• Max. 2500 pulses per revolution
• Output stage TTL with regulator UB 9...26 VDC

Baumer HG 22

• Incremental encoder with optical sensing
• Robust and wearless
• Max. 4000 pulses per revolution
• Output stage TTL with regulator UB 9...26 VDC

The HG16 from Baumer is a bearingless incremental encoder

• Operating temperature: -30...+100 °C
• Vibration: 10 g, 10-2000 Hz
• Impact: 100 g, 6 ms
• Weight: approx. 2.4 kg
• Connections: Terminal box or M23 flange connector, 12-pin

The Baumer HG18 is a bearingless incremental encoder

• Operating temperature: -30...+70 °C
• Vibration resistance: IEC 60068-2-6 (10 g, 10-2000 Hz)
• Impact resistance: IEC 60068-2-27 (100 g, 6 ms)
• Weight: approx. 4.2 kg
• Connection: Terminal box or M23 flange connector, 12-pin.

HMC16 is a bearingless incremental encoder

• Protection: IP 68 (encoder), IP 65 (signal processing)
• Material: aluminum alloy sensor head housing, stainless steel wheel (1.4104)
• Operating temperature: encoder -20 to +85 °C, signal processing 0 to +50 °C
• Vibration and shock resistance: vibration 25 g, 10-2000 Hz; shock 300 g, 12 ms12.

HMG 11

• Multiturn / SSI / Profibus / CANopen® / DeviceNet / PROFINET
• Optical sensing method
• Singleturn 13 bit, multiturn 12 bit / 16 bit
• Blind or through hollow shaft or cone shaft ø16...20 mm

HMG 161

• Reading method: Optical
• Size (flange): ø160 mm
• Power supply voltage: 9...30 VDC
• Function: Multiturn

• Incremental encoder (optionally programmable)
• HTL/TTL output driver for cable length up to 350 m
• Very high resistance to shock and vibrations
• Two-sided insulated bearing system with hybrid bearings
• Special protection against corrosion CX (C5-M)
• Large terminal box, turn by 180В°
• Support plate for torque arm 360В° freely positionable
• Mounting compatible with HOG10 encoders
• Function display via LEDs

• Magnetic sensing method
• Function display via LEDs
• Multiturn sensing with Energy Harvesting technology "MicroGen", without gear or battery
• Two-sided bearing system with hybrid bearings
• Special protection against corrosion CX (C5-M)

Incremental encoderHOG 10

• TTL output driver for cable length up to 550 m
• HTL output driver for cable length up to 350 m
• Very high resistance to shock and vibrations
• Hybrid bearing for extended service life
• Large terminal box, turn by 180° or axial terminal cover

HOG 10 + DSL.E

• Programming via included software (RS485 interface)
• Logic level HTL or TTL
• 512…2500 pulses per revolution
• Blind hollow shaft ø16 mm

HOG 10+ DSL.R

• Logic level HTL or TTL
• 512…2500 pulses per revolution
• Blind hollow shaft ø16 mm
• DSL.R: 3 outputs speed controlled (independent transistor outputs)
